42
STR-DE497P/K4800P/K5800P
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C1614 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1615 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1616 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1617 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1618 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1619 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1620 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1624 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1625 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1626 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1627 1-124-779-00 ELECT CHIP 10uF 20% 16V
C1632 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1633 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(DE497P)
C1634 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1635 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1636 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1671 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1905 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1906 1-128-396-11 ELECT CHIP 470uF 20% 10V
C1908 1-128-396-11 ELECT CHIP 470uF 20% 10V
C1909 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1910 1-128-396-11 ELECT CHIP 470uF 20% 10V
C1911 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1912 1-128-396-11 ELECT CHIP 470uF 20% 10V
C1913 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1914 1-126-204-11 ELECT CHIP 47uF 20% 16V
C1915 1-126-204-11 ELECT CHIP 47uF 20% 16V
(DE497P)
C1916 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(DE497P)
< CONNECTOR >
CNP5 1-779-978-11 PIN, CONNECTOR 3P
CNP6 1-784-929-11 PIN, CONNECTOR 14P
CNS1 1-764-865-41 CONNECTOR, BOARD TO BOARD 13P
CNS2 1-784-031-41 CONNECTOR, BOARD TO BOARD 8P
CNS4 1-569-308-11 SOCKET, CONNECTOR (L TYPE) 19P
CNS7 1-569-060-11 SOCKET, CONNECTOR 11P (K4800P/K5800P)
CNS7 1-569-321-11 SOCKET, CONNECTOR 15P (DE497P)
CNS8 1-569-315-11 SOCKET, CONNECTOR 5P
< DIODE >
D1001 8-719-016-74 DIODE 1SS352
D1101 8-719-988-61 DIODE 1SS355TE-17
D1501 8-719-049-09 DIODE 1SS367-T3SONY
D1502 8-719-049-09 DIODE 1SS367-T3SONY
D1601 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB1101 1-469-727-21 FERRITE, EMI (SMD) (2012)
FB1102 1-469-727-21 FERRITE, EMI (SMD) (2012)
FB1104 1-469-710-21 FERRITE, EMI (SMD) (2012)
FB1105 1-469-710-21 FERRITE, EMI (SMD) (2012)
FB1201 1-469-727-21 FERRITE, EMI (SMD) (2012)
FB1202 1-469-727-21 FERRITE, EMI (SMD) (2012)
FB1203 1-469-710-21 FERRITE, EMI (SMD) (2012)
FB1204 1-469-710-21 FERRITE, EMI (SMD) (2012)
FB1501 1-469-727-21 FERRITE, EMI (SMD) (2012)
FB1502 1-216-864-11 SHORT CHIP 0
FB1601 1-469-727-21 FERRITE, EMI (SMD) (2012)
FB1602 1-216-864-11 SHORT CHIP 0
FB1603 1-216-864-11 SHORT CHIP 0
< GROUND TERMINAL >
G1101 1-537-738-21 TERMINAL, GROUND
< IC >
IC1101 8-759-825-15 IC LC89056W-E
IC1102 8-759-242-70 IC TC7WU04F
IC1104 6-600-014-01 IC TORX141L (DIGITAL VIDEO 2 IN
(OPTICAL))
IC1201 8-759-698-76 IC CXD9617R
IC1202 6-704-037-01 IC IC61LV6416-15TG
IC1501 6-705-627-01 IC AK4626VQ
IC1503 8-759-231-53 IC TA7805S
IC1601 6-803-873-11 IC MB90478PF-G-170-BNDE1
IC1602 6-701-680-01 IC PST3629NR
IC1604 6-704-004-01 IC BR24L16F-WE2
IC1901 6-701-887-02 IC SI-3004KWF
IC1902 8-759-231-57 IC TA7810S
IC1903 6-705-464-01 IC BA50BC0T
IC1904 6-705-463-01 IC BA33BC0T
IC1905 6-702-771-01 IC TA78033LS (DE497P)
< JACK >
J1101 1-794-972-11 JACK, PIN 1P (DIGITAL DVD IN (COAXIAL))
< JUMPER RESISTOR >
JR1116 1-216-864-11 SHORT CHIP 0
JR1200 1-216-864-11 SHORT CHIP 0
JR1300 1-216-864-11 SHORT CHIP 0 (K4800P/K5800P)
JR1301 1-216-864-11 SHORT CHIP 0 (K4800P/K5800P)
JR1600 1-216-864-11 SHORT CHIP 0 (K4800P/K5800P)
L1901 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q1601 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q1602 8-729-230-49 TRANSISTOR 2SC2712-YG
< RESISTOR >
R1100 1-216-857-11 METAL CHIP 1M 5% 1/10W
R1101 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1102 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1103 1-216-809-11 METAL CHIP 100 5% 1/10W
R1104 1-216-809-11 METAL CHIP 100 5% 1/10W
R1105 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1106 1-216-839-11 METAL CHIP 33K 5% 1/10W
R1107 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R1108 1-216-809-11 METAL CHIP 100 5% 1/10W
R1109 1-216-809-11 METAL CHIP 100 5% 1/10W
R1110 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1111 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1112 1-216-809-11 METAL CHIP 100 5% 1/10W
R1113 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1114 1-216-809-11 METAL CHIP 100 5% 1/10W
