45
STR-DE497P/K4800P/K5800P
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R103 1-249-421-11 CARBON 2.2K 5% 1/4W
R104 1-247-847-11 CARBON 4.7K 5% 1/4W
R105 1-249-429-11 CARBON 10K 5% 1/4W
R106 1-247-863-11 CARBON 22K 5% 1/4W
R107 1-247-871-11 CARBON 47K 5% 1/4W
R111 1-247-831-11 CARBON 1K 5% 1/4W
R112 1-249-421-11 CARBON 2.2K 5% 1/4W
R113 1-249-421-11 CARBON 2.2K 5% 1/4W
R114 1-247-847-11 CARBON 4.7K 5% 1/4W
R115 1-249-429-11 CARBON 10K 5% 1/4W
R116 1-247-863-11 CARBON 22K 5% 1/4W
(DE497P)
R121 1-247-831-11 CARBON 1K 5% 1/4W
R122 1-249-421-11 CARBON 2.2K 5% 1/4W
R123 1-249-421-11 CARBON 2.2K 5% 1/4W
R141 1-249-421-11 CARBON 2.2K 5% 1/4W
R150 1-249-440-11 CARBON 82K 5% 1/4W
R153 1-247-807-31 CARBON 100 5% 1/4W
R154 1-249-393-11 CARBON 10 5% 1/4W F
R160 1-247-804-11 CARBON 75 5% 1/4W
R161 1-249-409-11 CARBON 220 5% 1/4W
R162 1-249-429-11 CARBON 10K 5% 1/4W
R175 1-249-393-11 CARBON 10 5% 1/4W F
R198 1-249-381-11 CARBON 1 5% 1/4W F
R199 1-249-381-11 CARBON 1 5% 1/4W F
< ROTARY ENCODER >
RV102 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
< SWITCH >
S100 1-771-410-21 SWITCH, TACTILE (INPUT MODE)
S101 1-771-410-21 SWITCH, TACTILE (>)
S102 1-771-410-21 SWITCH, TACTILE (–)
S103 1-771-410-21 SWITCH, TACTILE (+)
S104 1-771-410-21 SWITCH, TACTILE (<)
S105 1-771-410-21 SWITCH, TACTILE (TUNER FM/AM)
S106 1-771-410-21 SWITCH, TACTILE (MD/TAPE)
S107 1-771-410-21 SWITCH, TACTILE (VIDEO 1)
S110 1-771-410-21 SWITCH, TACTILE (MUSIC)
S111 1-771-410-21 SWITCH, TACTILE (MOVIE)
S112 1-771-410-21 SWITCH, TACTILE (A.F.D.)
S113 1-771-410-21 SWITCH, TACTILE (2CH)
S114 1-771-410-21 SWITCH, TACTILE (ENTER)
S115 1-771-410-21 SWITCH, TACTILE (MAIN MENU)
S116 1-771-410-21 SWITCH, TACTILE (MULTI CH IN) (DE497P)
S120 1-771-410-21 SWITCH, TACTILE (CD)
S121 1-771-410-21 SWITCH, TACTILE (DVD)
S125 1-771-410-21 SWITCH, TACTILE (VIDEO 2)
*************************************************************
HEADPHONE BOARD
*****************
< CONNECTOR >
CNP791 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
< JACK >
J791 1-815-314-21 JACK (PHONES)
*************************************************************
A-4750-435-A MAIN BOARD, COMPLETE (K4800P)
A-4750-441-A MAIN BOARD, COMPLETE (DE497P)
A-4752-285-A MAIN BOARD, COMPLETE (K5800P)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C371 1-161-494-00 CERAMIC 0.022uF 25V
C372 1-161-494-00 CERAMIC 0.022uF 25V
C373 1-161-494-00 CERAMIC 0.022uF 25V
C374 1-164-159-11 CERAMIC 0.1uF 50V
C375 1-161-494-00 CERAMIC 0.022uF 25V
C376 1-161-494-00 CERAMIC 0.022uF 25V
C400 1-164-159-11 CERAMIC 0.1uF 50V
C408 1-126-963-11 ELECT 4.7uF 20% 50V
C409 1-126-963-11 ELECT 4.7uF 20% 50V
C413 1-126-961-11 ELECT 2.2uF 20% 50V
C414 1-126-961-11 ELECT 2.2uF 20% 50V
C415 1-126-961-11 ELECT 2.2uF 20% 50V
C416 1-126-961-11 ELECT 2.2uF 20% 50V
C417 1-126-961-11 ELECT 2.2uF 20% 50V
C418 1-126-961-11 ELECT 2.2uF 20% 50V
C419 1-126-961-11 ELECT 2.2uF 20% 50V
C433 1-126-961-11 ELECT 2.2uF 20% 50V
C458 1-126-963-11 ELECT 4.7uF 20% 50V
C459 1-126-963-11 ELECT 4.7uF 20% 50V
C464 1-164-159-11 CERAMIC 0.1uF 50V
C465 1-126-934-11 ELECT 220uF 20% 16V
C467 1-164-159-11 CERAMIC 0.1uF 50V
C471 1-126-963-11 ELECT 4.7uF 20% 50V
C472 1-126-963-11 ELECT 4.7uF 20% 50V
C475 1-104-658-11 ELECT 100uF 20% 10V
C481 1-126-963-11 ELECT 4.7uF 20% 50V
C482 1-126-963-11 ELECT 4.7uF 20% 50V
C483 1-126-963-11 ELECT 4.7uF 20% 50V
C484 1-126-963-11 ELECT 4.7uF 20% 50V
C485 1-126-964-11 ELECT 10uF 20% 50V
C486 1-126-963-11 ELECT 4.7uF 20% 50V
C487 1-126-964-11 ELECT 10uF 20% 50V
C488 1-164-159-11 CERAMIC 0.1uF 50V
C489 1-128-809-11 CERAMIC 100PF 5% 50V
C490 1-128-809-11 CERAMIC 100PF 5% 50V
C491 1-126-963-11 ELECT 4.7uF 20% 50V
C492 1-126-963-11 ELECT 4.7uF 20% 50V
C493 1-126-963-11 ELECT 4.7uF 20% 50V
C494 1-126-963-11 ELECT 4.7uF 20% 50V
C495 1-126-963-11 ELECT 4.7uF 20% 50V
DISPLAY HEADPHONE MAIN
