41
STR-DE497P/K4800P/K5800P
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-4750-456-A DIGITAL BOARD, COMPLETE (DE497P)
A-4750-463-A DIGITAL BOARD, COMPLETE (K4800P/K5800P)
***********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C1101 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1102 1-126-204-11 ELECT CHIP 47uF 20% 16V
C1103 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1104 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1105 1-126-204-11 ELECT CHIP 47uF 20% 16V
C1106 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1107 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1108 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1109 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C1110 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C1111 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1112 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1113 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1114 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V
C1115 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1116 1-110-530-11 ELECT CHIP 1000uF 20% 6.3V
C1117 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1118 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C1119 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C1120 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1124 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1129 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C1130 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1131 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1201 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1202 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1203 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1204 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1205 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1206 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1207 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1208 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1209 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1210 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1211 1-128-396-11 ELECT CHIP 470uF 20% 10V
C1212 1-128-396-11 ELECT CHIP 470uF 20% 10V
C1213 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1214 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1216 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1218 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1219 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1220 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1229 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1230 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1231 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1300 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1301 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1302 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1303 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(DE497P)
C1304 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1315 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1365 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1502 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C1505 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1506 1-128-396-11 ELECT CHIP 470uF 20% 10V
C1507 1-124-779-00 ELECT CHIP 10uF 20% 16V
C1508 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1509 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1511 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1512 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C1513 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1514 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1515 1-128-396-11 ELECT CHIP 470uF 20% 10V
C1516 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C1517 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C1518 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C1519 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C1520 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C1521 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C1523 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C1552 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C1601 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1602 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1603 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1604 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1605 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1606 1-126-204-11 ELECT CHIP 47uF 20% 16V
C1608 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1610 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1611 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1612 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1613 1-164-156-11 CERAMIC CHIP 0.1uF 25V
DIGITAL
•Abbreviation
CND : Canadian model
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
