50
STR-DE497P/K4800P/K5800P
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
RR11 1-249-393-11 CARBON 10 5% 1/4W F
(DE497P)
RR12 1-249-393-11 CARBON 10 5% 1/4W F
(DE497P)
RR13 1-249-393-11 CARBON 10 5% 1/4W F
(DE497P)
RR14 1-249-393-11 CARBON 10 5% 1/4W F
(DE497P)
RR15 1-249-393-11 CARBON 10 5% 1/4W F
(DE497P)
< RELAY >
RY501 1-755-421-11 RELAY (12V)
RY560 1-755-267-11 RELAY
RY601 1-755-421-11 RELAY (12V)
RY701 1-755-421-11 RELAY (12V)
RY791 1-755-421-11 RELAY (12V)
< TERMINAL BOARD >
TM601 1-694-785-11 TERMINAL BOARD (SPEAKERS SURROUND)
TM602 1-694-805-11 TERMINAL BOARD (SPEAKERS
FRONT,CENTER)
*************************************************************
1-861-045-11 POWER BOARD
*************
< RESISTOR >
R124 1-247-847-11 CARBON 4.7K 5% 1/4W
< SWITCH >
S122 1-771-410-21 SWITCH, TACTILE (DIMMER)
S123 1-771-410-21 SWITCH, TACTILE (DISPLAY)
S152 1-771-410-21 SWITCH, TACTILE (?/1)
*************************************************************
A-4750-409-A STANDBY BOARD, COMPLETE (DE497P)
A-4750-608-A STANDBY BOARD, COMPLETE
(K4800P/K5800P)
************************
1-533-217-41 HOLDER, FUSE
< CAPACITOR >
C801 1-126-947-11 ELECT 47uF 20% 35V
C802 1-126-947-11 ELECT 47uF 20% 35V
C813 1-164-159-11 CERAMIC 0.1uF 50V
C814 1-164-159-11 CERAMIC 0.1uF 50V
C815 1-126-943-11 ELECT 2200uF 20% 25V
C816 1-126-942-61 ELECT 1000uF 20% 25V
C820 1-164-159-11 CERAMIC 0.1uF 50V
C821 1-164-159-11 CERAMIC 0.1uF 50V
C822 1-126-947-11 ELECT 47uF 20% 35V
C823 1-126-936-11 ELECT 3300uF 20% 16V
C830 1-164-159-11 CERAMIC 0.1uF 50V
C831 1-164-159-11 CERAMIC 0.1uF 50V
C920 1-164-159-11 CERAMIC 0.1uF 50V
C921 1-164-159-11 CERAMIC 0.1uF 50V
C923 1-126-959-11 ELECT 0.47uF 20% 50V
C950 1-126-936-11 ELECT 3300uF 20% 16V
< CONNECTOR >
CNP802 1-779-977-11 PIN, CONNECTOR 6P
CNP804 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
CNP901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CNP902 1-794-577-21 PIN, CONNECTOR (POWER) 2P
CNP903 1-564-506-11 PLUG, CONNECTOR 3P
CNP905 1-793-673-11 CONNECTOR, BOARD TO BOARD 7P
CNP912 1-779-978-11 PIN, CONNECTOR 3P
< DIODE >
D801 8-719-933-95 DIODE HZS20-1L
D804 8-719-068-28 DIODE HZ6.8BP-TK
D812 6-500-522-11 DIODE 10EDB40-TA2B5
D813 6-500-522-11 DIODE 10EDB40-TA2B5
D814 6-500-522-11 DIODE 10EDB40-TA2B5
D815 6-500-522-11 DIODE 10EDB40-TA2B5
D820 6-500-522-11 DIODE 10EDB40-TA2B5
D821 6-500-522-11 DIODE 10EDB40-TA2B5
D822 6-500-522-11 DIODE 10EDB40-TA2B5
D823 6-500-522-11 DIODE 10EDB40-TA2B5
D901 8-719-991-33 DIODE 1SS133T-77
D910 6-500-522-11 DIODE 10EDB40-TA2B5
D911 6-500-522-11 DIODE 10EDB40-TA2B5
D912 6-500-522-11 DIODE 10EDB40-TA2B5
D913 6-500-522-11 DIODE 10EDB40-TA2B5
D914 8-719-991-33 DIODE 1SS133T-77
D915 8-719-991-33 DIODE 1SS133T-77
< EARTH TERMINAL >
* G901 1-537-738-21 TERMINAL, EARTH (K4800P/K5800P)
< TRANSISTOR >
Q801 8-729-140-97 TRANSISTOR 2SB734-34
Q901 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q921 8-729-119-79 TRANSISTOR 2SC2785-FEK
< RESISTOR >
R804 1-249-429-11 CARBON 10K 5% 1/4W
R806 1-247-863-11 CARBON 22K 5% 1/4W
0 R810 1-243-634-11 FUSIBLE 0.22 5% 1/2W F
0 R812 1-243-634-11 FUSIBLE 0.22 5% 1/2W F
0 R901 1-219-237-11 SOLID 3.3M 20% 1/2W F
(US,CND)
R902 1-247-871-11 CARBON 47K 5% 1/4W
R903 1-247-847-11 CARBON 4.7K 5% 1/4W
R904 1-249-381-11 CARBON 1 5% 1/4W F
0 R910 1-243-635-11 FUSIBLE 0.33 5% 1/2W F
R921 1-247-871-11 CARBON 47K 5% 1/4W
R922 1-249-435-11 CARBON 33K 5% 1/4W
R923 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0 RY901 1-755-276-31 RELAY, POWER
< TRANSFORMER >
0 T902 1-435-281-11 TRANSFORMER, POWER (US,CND)
