55
STR-DE598/DE698/DV10
Ver. 1.1
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R1520 1-216-813-11 METAL CHIP 220 5% 1/10W
R1521 1-216-813-11 METAL CHIP 220 5% 1/10W
R1522 1-216-813-11 METAL CHIP 220 5% 1/10W
R1523 1-216-813-11 METAL CHIP 220 5% 1/10W
R1524 1-216-864-11 SHORT CHIP 0
R1525 1-216-813-11 METAL CHIP 220 5% 1/10W
R1526 1-216-813-11 METAL CHIP 220 5% 1/10W
R1527 1-216-813-11 METAL CHIP 220 5% 1/10W
R1528 1-216-813-11 METAL CHIP 220 5% 1/10W
R1530 1-216-809-11 METAL CHIP 100 5% 1/10W
(DE698/DV10)
R1531 1-216-809-11 METAL CHIP 100 5% 1/10W
(DE698/DV10)
R1532 1-216-813-11 METAL CHIP 220 5% 1/10W
R1533 1-216-813-11 METAL CHIP 220 5% 1/10W
R1534 1-216-813-11 METAL CHIP 220 5% 1/10W
R1535 1-216-813-11 METAL CHIP 220 5% 1/10W
R1536 1-216-813-11 METAL CHIP 220 5% 1/10W
R1537 1-216-813-11 METAL CHIP 220 5% 1/10W
R1538 1-216-813-11 METAL CHIP 220 5% 1/10W
R1539 1-216-813-11 METAL CHIP 220 5% 1/10W
R1540 1-216-813-11 METAL CHIP 220 5% 1/10W
R1541 1-216-813-11 METAL CHIP 220 5% 1/10W
R1542 1-216-813-11 METAL CHIP 220 5% 1/10W
R1543 1-216-813-11 METAL CHIP 220 5% 1/10W
R1544 1-216-813-11 METAL CHIP 220 5% 1/10W
R1545 1-216-813-11 METAL CHIP 220 5% 1/10W
R1546 1-216-813-11 METAL CHIP 220 5% 1/10W
R1547 1-216-813-11 METAL CHIP 220 5% 1/10W
R1548 1-216-813-11 METAL CHIP 220 5% 1/10W
R1549 1-216-813-11 METAL CHIP 220 5% 1/10W
R1550 1-216-813-11 METAL CHIP 220 5% 1/10W
R1551 1-216-813-11 METAL CHIP 220 5% 1/10W
R1552 1-216-813-11 METAL CHIP 220 5% 1/10W
R1553 1-216-813-11 METAL CHIP 220 5% 1/10W
R1554 1-216-813-11 METAL CHIP 220 5% 1/10W
R1555 1-216-813-11 METAL CHIP 220 5% 1/10W
R1556 1-216-809-11 METAL CHIP 100 5% 1/10W
R1570 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1571 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1572 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1573 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1574 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1587 1-216-813-11 METAL CHIP 220 5% 1/10W
(DE698/DV10)
R1588 1-216-833-11 METAL CHIP 10K 5% 1/10W
(DE698/DV10)
R1635 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1636 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
< VIBRATOR >
X1101 1-813-448-21 OSCILLATOR, PIEZOELECTRIC (24MHz)
X1301 1-795-126-21 VIBRATOR, CRYSTAL (12.288MHz)
X1502 1-813-276-21 QUARTZ, CRYSTAL (13.9MHz)
*************************************************************
A-1084-338-A DISPLAY BOARD, COMPLETE (DE598)
A-1084-994-A DISPLAY BOARD, COMPLETE (DE698/DV10)
************************
< CAPACITOR >
C100 1-127-888-11 CERAMIC 0.1uF 10% 50V
C101 1-127-888-11 CERAMIC 0.1uF 10% 50V
C104 1-113-342-11 CERAMIC 0.1uF 50V
(DE598)
C104 1-127-888-11 CERAMIC 0.1uF 10% 50V
(DE698/DV10)
C105 1-126-795-11 ELECT 10uF 20% 50V
C106 1-127-868-11 CERAMIC 0.0022uF 10% 50V
(DE698/DV10)
C107 1-127-868-11 CERAMIC 0.0022uF 10% 50V
(DE698/DV10)
C108 1-127-888-11 CERAMIC 0.1uF 10% 50V
C109 1-127-888-11 CERAMIC 0.1uF 10% 50V
C110 1-162-286-31 CERAMIC 220PF 10% 50V
C111 1-162-286-31 CERAMIC 220PF 10% 50V
C112 1-162-286-31 CERAMIC 220PF 10% 50V
C114 1-127-888-11 CERAMIC 0.1uF 10% 50V
C115 1-126-795-11 ELECT 10uF 20% 50V
C132 1-162-286-31 CERAMIC 220PF 10% 50V
C133 1-162-286-31 CERAMIC 220PF 10% 50V
C134 1-162-286-31 CERAMIC 220PF 10% 50V
C135 1-162-286-31 CERAMIC 220PF 10% 50V
C136 1-162-286-31 CERAMIC 220PF 10% 50V
C137 1-162-286-31 CERAMIC 220PF 10% 50V
C138 1-162-286-31 CERAMIC 220PF 10% 50V
C139 1-162-286-31 CERAMIC 220PF 10% 50V
C140 1-162-286-31 CERAMIC 220PF 10% 50V
C141 1-162-286-31 CERAMIC 220PF 10% 50V
C142 1-162-286-31 CERAMIC 220PF 10% 50V
C143 1-162-286-31 CERAMIC 220PF 10% 50V
C144 1-127-888-11 CERAMIC 0.1uF 10% 50V
C150 1-127-888-11 CERAMIC 0.1uF 10% 50V
C151 1-126-795-11 ELECT 10uF 20% 50V
C152 1-162-286-31 CERAMIC 220PF 10% 50V
C153 1-162-286-31 CERAMIC 220PF 10% 50V
C154 1-162-286-31 CERAMIC 220PF 10% 50V
C155 1-127-888-11 CERAMIC 0.1uF 10% 50V
C156 1-127-888-11 CERAMIC 0.1uF 10% 50V
C157 1-127-888-11 CERAMIC 0.1uF 10% 50V
< CONNECTOR >
CNS100 1-568-838-11 CONNECTOR, FFC 21P
< DIODE >
D101 8-719-061-96 LED SLR-325DCT31 (2CH)
D102 8-719-061-96 LED SLR-325DCT31 (MUSIC)
D103 8-719-061-96 LED SLR-325DCT31 (MOVIE)
D104 8-719-061-96 LED SLR-325DCT31 (A.F.D.)
D105 6-500-647-01 LED SEL5E20C-STP15
(MULTI CHANNEL DECODING)
< VACUUM FLUORESCENT DISPLAY >
FL101 1-518-966-11 VACUUM FLUORESCENT DISPLAY
