56
STR-DE598/DE698/DV10
Ver. 1.1
Ref. No. Part No. Description Remark
< IC >
IC100 8-759-643-83 IC uPD16315GB-3BS
IC101 8-759-036-90 IC MC74ACT08N
IC102 6-600-349-31 IC NJL24H400A (IR)
< TRANSISTOR >
Q110 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R101 1-249-409-11 CARBON 220 5% 1/4W
R102 1-249-411-11 CARBON 330 5% 1/4W
R103 1-249-413-11 CARBON 470 5% 1/4W
R104 1-249-415-11 CARBON 680 5% 1/4W
R105 1-247-831-00 CARBON 1K 5% 1/4W
R106 1-249-419-11 CARBON 1.5K 5% 1/4W
R107 1-249-421-11 CARBON 2.2K 5% 1/4W
R108 1-247-847-00 CARBON 4.7K 5% 1/4W
R109 1-249-429-11 CARBON 10K 5% 1/4W
R110 1-249-435-11 CARBON 33K 5% 1/4W
(DE598)
R111 1-249-421-11 CARBON 2.2K 5% 1/4W
R121 1-249-409-11 CARBON 220 5% 1/4W
R122 1-249-411-11 CARBON 330 5% 1/4W
R123 1-249-413-11 CARBON 470 5% 1/4W
R124 1-249-415-11 CARBON 680 5% 1/4W
R125 1-247-831-00 CARBON 1K 5% 1/4W
R128 1-249-419-11 CARBON 1.5K 5% 1/4W
R142 1-249-409-11 CARBON 220 5% 1/4W
R143 1-249-411-11 CARBON 330 5% 1/4W
R144 1-249-413-11 CARBON 470 5% 1/4W
R148 1-249-415-11 CARBON 680 5% 1/4W
R154 1-249-393-11 CARBON 10 5% 1/4W F
R155 1-247-807-31 CARBON 100 5% 1/4W
R160 1-249-409-11 CARBON 220 5% 1/4W
R161 1-247-804-11 CARBON 75 5% 1/4W
R162 1-249-429-11 CARBON 10K 5% 1/4W
R171 1-249-440-11 CARBON 82K 5% 1/4W
R172 1-247-807-31 CARBON 100 5% 1/4W
R173 1-247-807-31 CARBON 100 5% 1/4W
R174 1-247-807-31 CARBON 100 5% 1/4W
R175 1-249-393-11 CARBON 10 5% 1/4W F
R198 1-249-381-11 CARBON 1 5% 1/4W F
R199 1-249-381-11 CARBON 1 5% 1/4W F
< ROTARY ENCODER >
RV101 1-418-817-11 ENCODER, ROTARY (–/+) (DE698/DV10)
RV102 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
< SWITCH >
S100 1-771-410-21 SWITCH, TACTILE (>)
S101 1-771-410-21 SWITCH, TACTILE (INPUT MODE)
S102 1-771-410-21 SWITCH, TACTILE (DVD)
S103 1-771-410-21 SWITCH, TACTILE (MD/TAPE)
S104 1-771-410-21 SWITCH, TACTILE (SA-CD/CD)
S105 1-771-410-21 SWITCH, TACTILE (FM) (DE598)
S105 1-771-410-21 SWITCH, TACTILE (TUNER FM/AM)
(DE698/DV10)
S106 1-771-410-21 SWITCH, TACTILE (MAIN MENU)
S107 1-771-410-21 SWITCH, TACTILE (ENTER)
S108 1-771-410-21 SWITCH, TACTILE (<)
S109 1-771-410-21 SWITCH, TACTILE (+) (DE598)
S110 1-771-410-21 SWITCH, TACTILE (AM) (DE598)
S110 1-771-410-21 SWITCH, TACTILE (AUX) (DE698/DV10)
S120 1-771-410-21 SWITCH, TACTILE (SURR BACK DECODING)
S121 1-771-410-21 SWITCH, TACTILE (MUSIC)
S122 1-771-410-21 SWITCH, TACTILE (MOVIE)
S123 1-771-410-21 SWITCH, TACTILE (A.F.D.)
S124 1-771-410-21 SWITCH, TACTILE (2CH)
S125 1-771-410-21 SWITCH, TACTILE (MULTI CH IN)
S140 1-771-410-21 SWITCH, TACTILE (–) (DE598)
S141 1-771-410-21 SWITCH, TACTILE (VIDEO 3)
S142 1-771-410-21 SWITCH, TACTILE (VIDEO 2)
S143 1-771-410-21 SWITCH, TACTILE (VIDEO 1)
*************************************************************
HEADPHONE BOARD
*****************
< CAPACITOR >
C790 1-127-888-11 CERAMIC 0.1uF 10% 50V
< CONNECTOR >
CNP791 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
< JACK >
J791 1-815-314-21 JACK (PHONES)
*************************************************************
A-1084-332-A MAIN BOARD, COMPLETE (DE598:US,E2)
A-1084-399-A MAIN BOARD, COMPLETE (DE598:CND)
A-1084-404-A MAIN BOARD, COMPLETE (DE598:AEP,UK)
A-1084-563-A MAIN BOARD, COMPLETE (DE698:US,E2/DV10)
A-1084-705-A MAIN BOARD, COMPLETE (DE698:CND)
A-1085-097-A MAIN BOARD, COMPLETE (DE698:AEP,UK)
A-1097-809-A MAIN BOARD, COMPLETE
(DE598:AUS,AR,KR,TW)
A-1097-810-A MAIN BOARD, COMPLETE (DE698:AUS,AR)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C400 1-127-868-11 CERAMIC 0.0022uF 10% 50V
C403 1-127-868-11 CERAMIC 0.0022uF 10% 50V
C408 1-126-963-11 ELECT 4.7uF 20% 50V
C409 1-126-963-11 ELECT 4.7uF 20% 50V
C444 1-127-868-11 CERAMIC 0.0022uF 10% 50V
C445 1-127-868-11 CERAMIC 0.0022uF 10% 50V
C458 1-126-963-11 ELECT 4.7uF 20% 50V
C459 1-126-963-11 ELECT 4.7uF 20% 50V
C464 1-127-888-11 CERAMIC 0.1uF 10% 50V
C468 1-162-282-31 CERAMIC 100PF 10% 50V
C469 1-162-282-31 CERAMIC 100PF 10% 50V
C471 1-126-963-11 ELECT 4.7uF 20% 50V
Ref. No. Part No. Description Remark
DISPLAY HEADPHONE MAIN
