65
STR-DE598/DE698/DV10
Ver. 1.1
Q251 8-729-201-53 TRANSISTOR 2SA1015-GR (DE698)
< RESISTOR >
R206 1-247-804-11 CARBON 75 5% 1/4W
(DE698/DV10)
R251 1-247-804-11 CARBON 75 5% 1/4W
(DE698/DV10)
R252 1-247-804-11 CARBON 75 5% 1/4W
(DE698/DV10)
R253 1-247-804-11 CARBON 75 5% 1/4W
(DE698/DV10)
R254 1-247-804-11 CARBON 75 5% 1/4W
(DE698/DV10)
R255 1-247-804-11 CARBON 75 5% 1/4W
(DE698/DV10)
R257 1-247-804-11 CARBON 75 5% 1/4W
(DE698/DV10)
R258 1-247-804-11 CARBON 75 5% 1/4W
(DE698/DV10)
R259 1-247-804-11 CARBON 75 5% 1/4W
(DE698/DV10)
R260 1-247-804-11 CARBON 75 5% 1/4W
(DE698/DV10)
R261 1-249-429-11 CARBON 10K 5% 1/4W
(DE698)
R262 1-249-421-11 CARBON 2.2K 5% 1/4W
(DE698)
R263 1-249-411-11 CARBON 330 5% 1/4W
(DE698)
R264 1-247-883-00 CARBON 150K 5% 1/4W
(DE698)
< RELAY >
RY250 1-755-184-11 RELAY (DE698)
*************************************************************
A-1084-974-A S-VIDEO UP CONVERT BOARD, COMPLETE
(DE698:US,CND)
A-1085-099-A S-VIDEO UP CONVERT BOARD, COMPLETE
(DE698:AEP,UK,AUS)
A-1097-712-A S-VIDEO UP CONVERT BOARD, COMPLETE
(DE698:E2,AR)
***********************************
< CAPACITOR >
C341 1-162-199-31 CERAMIC 10PF 5% 50V
(DE698:US,CND,E2,AR)
C351 1-162-211-31 CERAMIC 33PF 5% 50V
(DE698:US,CND,E2,AR)
C352 1-127-888-11 CERAMIC 0.1uF 10% 50V
(DE698)
C353 1-104-658-11 ELECT 100uF 20% 10V
(DE698)
C354 1-127-876-11 CERAMIC 0.01uF 10% 50V
(DE698)
C355 1-126-959-11 ELECT 0.47uF 20% 50V
(DE698)
C356 1-127-876-11 CERAMIC 0.01uF 10% 50V
(DE698)
C357 1-127-876-11 CERAMIC 0.01uF 10% 50V
(DE698)
C358 1-162-201-31 CERAMIC 12PF 5% 50V
(DE698)
C362 1-126-925-11 ELECT 470uF 20% 10V
(DE698)
C363 1-128-801-11 CERAMIC 22PF 5% 50V
(DE698)
C364 1-162-201-31 CERAMIC 12PF 5% 50V
(DE698)
C365 1-126-947-11 ELECT 47uF 20% 35V
(DE698)
C366 1-127-888-11 CERAMIC 0.1uF 10% 50V
(DE698)
C367 1-127-876-11 CERAMIC 0.01uF 10% 50V
(DE698)
C368 1-126-963-11 ELECT 4.7uF 20% 50V
(DE698)
C369 1-130-495-00 MYLAR 0.1uF 5% 50V
(DE698)
C371 1-128-801-11 CERAMIC 22PF 5% 50V
(DE698)
C372 1-162-201-31 CERAMIC 12PF 5% 50V
(DE698)
C373 1-128-801-11 CERAMIC 22PF 5% 50V
(DE698)
C374 1-126-925-11 ELECT 470uF 20% 10V
(DE698)
C375 1-126-965-11 ELECT 22uF 20% 50V
(DE698)
C376 1-126-947-11 ELECT 47uF 20% 35V
(DE698)
C377 1-127-888-11 CERAMIC 0.1uF 10% 50V
(DE698)
C378 1-127-888-11 CERAMIC 0.1uF 10% 50V
(DE698)
C379 1-128-812-11 CERAMIC 180PF 5% 50V
(DE698)
C380 1-127-876-11 CERAMIC 0.01uF 10% 50V
(DE698)
C381 1-127-876-11 CERAMIC 0.01uF 10% 50V
(DE698)
C382 1-127-888-11 CERAMIC 0.1uF 10% 50V
(DE698)
C383 1-104-658-11 ELECT 100uF 20% 10V
(DE698)
C384 1-127-888-11 CERAMIC 0.1uF 10% 50V
(DE698)
C385 1-127-876-11 CERAMIC 0.01uF 10% 50V
(DE698)
C386 1-104-658-11 ELECT 100uF 20% 10V
(DE698)
C387 1-127-876-11 CERAMIC 0.01uF 10% 50V
(DE698)
C388 1-127-876-11 CERAMIC 0.01uF 10% 50V
(DE698)
C389 1-127-888-11 CERAMIC 0.1uF 10% 50V
(DE698)
C390 1-104-658-11 ELECT 100uF 20% 10V
(DE698)
C392 1-162-199-31 CERAMIC 10PF 5% 50V
(DE698:AEP,UK,AUS)
C393 1-128-802-11 CERAMIC 27PF 5% 50V
(DE698:AEP,UK,AUS)
C394 1-126-947-11 ELECT 47uF 20% 35V
(DE698)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
S-VIDEO S-VIDEO UP CONVERT
