Sony STR-DE598 - Page 66

66
STR-DE598/DE698/DV10
Ver. 1.1
C395 1-127-888-11 CERAMIC 0.1uF 10% 50V
(DE698)
C397 1-127-888-11 CERAMIC 0.1uF 10% 50V
(DE698)
< CONNECTOR >
CNS351 1-568-442-11 SOCKET, CONNECTOR 9P (DE698)
< TRIMMER CAPACITOR >
CT380 1-141-442-91 CAP, CERAMIC TRIMMER 20PF
(DE698:US,CND,E2,AR)
CT381 1-141-442-91 CAP, CERAMIC TRIMMER 20PF
(DE698:AEP,UK,AUS)
< FERRITE BEAD >
FB353 1-412-911-11 INDUCTOR, FERRITE BEAD (DE698)
FB354 1-412-911-11 INDUCTOR, FERRITE BEAD (DE698)
FB355 1-412-911-11 INDUCTOR, FERRITE BEAD (DE698)
< IC >
IC370 6-701-597-01 IC TC90A69N (DE698)
IC371 8-759-917-18 IC SN74HCU04AN (DE698)
IC372 6-803-031-01 IC NJM2268D (DE698)
IC373 8-759-232-01 IC TC74HC00AP (DE698:AEP,UK,AUS)
< COIL >
L370 1-410-514-11 INDUCTOR 27uH (DE698)
L371 1-410-514-11 INDUCTOR 27uH (DE698)
L372 1-414-189-31 INDUCTOR 100uH (DE698)
L373 1-414-189-31 INDUCTOR 100uH (DE698)
L374 1-410-514-11 INDUCTOR 27uH (DE698)
L376 1-414-189-31 INDUCTOR 100uH (DE698)
L377 1-414-189-31 INDUCTOR 100uH (DE698)
< TRANSISTOR >
Q371 8-729-119-78 TRANSISTOR 2SC2785-HFE (DE698)
Q372 8-729-119-78 TRANSISTOR 2SC2785-HFE (DE698)
Q373 8-729-119-78 TRANSISTOR 2SC2785-HFE (DE698)
< RESISTOR >
R358 1-247-831-00 CARBON 1K 5% 1/4W
(DE698)
R359 1-247-831-00 CARBON 1K 5% 1/4W
(DE698)
R363 1-247-903-00 CARBON 1M 5% 1/4W
(DE698)
R365 1-247-807-31 CARBON 100 5% 1/4W
(DE698)
R366 1-247-807-31 CARBON 100 5% 1/4W
(DE698)
R367 1-249-429-11 CARBON 10K 5% 1/4W
(DE698)
R368 1-247-843-11 CARBON 3.3K 5% 1/4W
(DE698)
R369 1-247-843-11 CARBON 3.3K 5% 1/4W
(DE698)
R373 1-249-416-11 CARBON 820 5% 1/4W
(DE698)
R374 1-247-903-00 CARBON 1M 5% 1/4W
(DE698)
Ref. No. Part No. Description Remark
S-VIDEO UP CONVERT
R375 1-249-424-11 CARBON 3.9K 5% 1/4W
(DE698)
R376 1-247-831-00 CARBON 1K 5% 1/4W
(DE698)
R377 1-249-416-11 CARBON 820 5% 1/4W
(DE698)
R378 1-249-416-11 CARBON 820 5% 1/4W
(DE698)
R379 1-249-416-11 CARBON 820 5% 1/4W
(DE698)
R382 1-249-418-11 CARBON 1.2K 5% 1/4W
(DE698)
R383 1-249-420-11 CARBON 1.8K 5% 1/4W
(DE698)
R384 1-249-424-11 CARBON 3.9K 5% 1/4W
(DE698)
R385 1-249-416-11 CARBON 820 5% 1/4W
(DE698)
R386 1-247-807-31 CARBON 100 5% 1/4W
(DE698)
R387 1-247-903-00 CARBON 1M 5% 1/4W
(DE698:AEP,UK,AUS)
R388 1-247-903-00 CARBON 1M 5% 1/4W
(DE698:US,CND,E2,AR)
R389 1-249-411-11 CARBON 330 5% 1/4W
(DE698:US,CND,E2,AR)
R390 1-247-807-31 CARBON 100 5% 1/4W
(DE698:US,CND,E2,AR)
R391 1-247-807-31 CARBON 100 5% 1/4W
(DE698:AEP,UK,AUS)
R392 1-249-411-11 CARBON 330 5% 1/4W
(DE698:AEP,UK,AUS)
R393 1-249-430-11 CARBON 12K 5% 1/4W
(DE698)
R394 1-249-430-11 CARBON 12K 5% 1/4W
(DE698)
< VIBRATOR >
X370 1-781-134-21 VIBRATOR, CRYSTAL (4.43MHz)
(DE698:AEP,UK,AUS)
X371 1-781-342-21 OSCILLATOR, CRYSTAL (3.58MHz)
(DE698:US,CND,E2,AR)
*************************************************************
TUNING BOARD
*************
< CONNECTOR >
* CNP104 1-564-517-11 PLUG, CONNECTOR 2P
< RESISTOR >
R149 1-247-831-00 CARBON 1K 5% 1/4W
R150 1-249-419-11 CARBON 1.5K 5% 1/4W
R151 1-249-421-11 CARBON 2.2K 5% 1/4W
R152 1-247-847-00 CARBON 4.7K 5% 1/4W
R153 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S148 1-771-410-21 SWITCH, TACTILE (TUNING –)
S149 1-771-410-21 SWITCH, TACTILE (FM MODE)
S150 1-771-410-21 SWITCH, TACTILE (MEMORY)
S151 1-771-410-21 SWITCH, TACTILE (PRESET TUNING –)
Ref. No. Part No. Description Remark
TUNING
