67
STR-DE598/DE698/DV10
Ver. 1.1
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
S152 1-771-410-21 SWITCH, TACTILE (PRESET TUNING +)
S153 1-771-410-21 SWITCH, TACTILE (TUNING +)
*************************************************************
A-1084-344-A VIDEO BOARD, COMPLETE
(DE598:EXCEPT AEP,UK)
A-1084-408-A VIDEO BOARD, COMPLETE (DE598:AEP,UK)
A-1084-442-A VIDEO BOARD, COMPLETE (DE698)
A-1097-367-A VIDEO BOARD, COMPLETE (DV10)
**********************
< CAPACITOR >
C200 1-128-805-11 CERAMIC 47PF 5% 50V
C201 1-128-805-11 CERAMIC 47PF 5% 50V
C206 1-126-964-11 ELECT 10uF 20% 50V
C207 1-126-964-11 ELECT 10uF 20% 50V
C208 1-126-964-11 ELECT 10uF 20% 50V
C209 1-126-964-11 ELECT 10uF 20% 50V
C210 1-126-964-11 ELECT 10uF 20% 50V
C213 1-126-923-11 ELECT 220uF 20% 10V
C214 1-127-888-11 CERAMIC 0.1uF 10% 50V
C215 1-127-888-11 CERAMIC 0.1uF 10% 50V
C220 1-126-947-11 ELECT 47uF 20% 35V
C221 1-126-923-11 ELECT 220uF 20% 10V
C223 1-127-888-11 CERAMIC 0.1uF 10% 50V
C224 1-127-888-11 CERAMIC 0.1uF 10% 50V
C308 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT DE598:AEP,UK)
C309 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT DE598:AEP,UK)
C310 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT DE598:AEP,UK)
C311 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT DE598:AEP,UK)
C312 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT DE598:AEP,UK)
C313 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT DE598:AEP,UK)
C314 1-127-868-11 CERAMIC 0.0022uF 10% 50V
C315 1-127-868-11 CERAMIC 0.0022uF 10% 50V
(EXCEPT DE598:AEP,UK)
C316 1-127-868-11 CERAMIC 0.0022uF 10% 50V
C317 1-126-947-11 ELECT 47uF 20% 35V
(EXCEPT DE598:AEP,UK)
C330 1-127-888-11 CERAMIC 0.1uF 10% 50V
(EXCEPT DE598:AEP,UK)
C331 1-127-888-11 CERAMIC 0.1uF 10% 50V
(EXCEPT DE598:AEP,UK)
C338 1-126-947-11 ELECT 47uF 20% 35V
(EXCEPT DE598:AEP,UK)
< CONNECTOR >
* CNP202 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P (DE598)
* CNP202 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
(DE698/DV10)
CNP203 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
CNS201 1-568-442-11 SOCKET, CONNECTOR 9P (DE698/DV10)
CNS202 1-568-442-11 SOCKET, CONNECTOR 9P (DE698)
CNS250 1-568-443-11 SOCKET, CONNECTOR 13P
< DIODE >
D203 8-719-991-33 DIODE 1SS133T-77
D204 8-719-991-33 DIODE 1SS133T-77
< IC >
IC203 6-701-890-01 IC NJM2595D
IC304 6-707-363-01 IC NJM2586L (EXCEPT DE598:AEP,UK)
IC804 8-759-245-79 IC TA79005S
IC807 8-759-231-53 IC TA7805S
< JACK >
J200 1-794-978-11 JACK, PIN 3P (DVD VIDEO IN,
VIDEO 2 VIDEO IN,VIDEO 1 VIDEO OUT)
J201 1-815-043-11 JACK, PIN 2P (VIDEO 1 VIDEO IN,
MONITOR VIDEO OUT)
J301 1-816-592-11 JACK, PIN 9P (COMPONENT VIDEO
DVD IN (ASSIGNABLE),
VIDEO 2 IN (ASSIGNABLE),MONITOR OUT)
(EXCEPT DE598:AEP,UK)
< RESISTOR >
R200 1-247-804-11 CARBON 75 5% 1/4W
R201 1-247-804-11 CARBON 75 5% 1/4W
R218 1-247-804-11 CARBON 75 5% 1/4W
R219 1-247-804-11 CARBON 75 5% 1/4W
R220 1-247-804-11 CARBON 75 5% 1/4W
R221 1-247-804-11 CARBON 75 5% 1/4W
R301 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DE598:AEP,UK)
R302 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DE598:AEP,UK)
R303 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DE598:AEP,UK)
R304 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DE598:AEP,UK)
R305 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DE598:AEP,UK)
R306 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DE598:AEP,UK)
R307 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DE598:AEP,UK)
R308 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DE598:AEP,UK)
R309 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DE598:AEP,UK)
R310 1-247-831-00 CARBON 1K 5% 1/4W
(EXCEPT DE598:AEP,UK)
R311 1-247-831-00 CARBON 1K 5% 1/4W
(EXCEPT DE598:AEP,UK)
R312 1-247-831-00 CARBON 1K 5% 1/4W
(EXCEPT DE598:AEP,UK)
R313 1-247-863-00 CARBON 22K 5% 1/4W
(EXCEPT DE598:AEP,UK)
*************************************************************
