68
STR-DE598/DE698/DV10
Ver. 1.1
VIDEO3 BOARD (DE598)
*************
< CAPACITOR >
C293 1-127-888-11 CERAMIC 0.1uF 10% 50V
C294 1-127-888-11 CERAMIC 0.1uF 10% 50V
C298 1-162-286-31 CERAMIC 220PF 10% 50V
C299 1-162-286-31 CERAMIC 220PF 10% 50V
< CONNECTOR >
CN201 1-784-922-11 PIN, CONNECTOR 5P
< JACK >
J298 1-819-187-11 JACK, PIN 3P (VIDEO 3 INPUT
VIDEO,AUDIO L/R)
< RESISTOR >
R298 1-247-831-00 CARBON 1K 5% 1/4W
R299 1-247-831-00 CARBON 1K 5% 1/4W
< LEAD WIRE >
* W290 1-690-880-31 LEAD (WITH CONNECTOR)
*************************************************************
VIDEO3 (DE61) BOARD (DE698/DV10)
*******************
< CAPACITOR >
C293 1-127-888-11 CERAMIC 0.1uF 10% 50V
C294 1-127-888-11 CERAMIC 0.1uF 10% 50V
C298 1-162-286-31 CERAMIC 220PF 10% 50V
C299 1-162-286-31 CERAMIC 220PF 10% 50V
< CONNECTOR >
CN201 1-784-922-21 PIN, CONNECTOR 5P
< JACK >
J298 1-819-187-11 JACK, PIN 3P (VIDEO 3 INPUT
VIDEO,AUDIO L/R)
< RESISTOR >
R298 1-247-831-00 CARBON 1K 5% 1/4W
R299 1-247-831-00 CARBON 1K 5% 1/4W
< LEAD WIRE >
* W290 1-690-880-31 LEAD (WITH CONNECTOR)
*************************************************************
VIDEO3 (DE61)
MISCELLANEOUS
***************
102 1-828-963-11 WIRE (FLAT TYPE) (11 CORE) (EXCEPT AEP,UK)
102 1-828-980-11 WIRE (FLAT TYPE) (15 CORE) (AEP,UK)
103 1-828-972-11 WIRE (FLAT TYPE) (13 CORE)
105 1-828-954-11 WIRE (FLAT TYPE) (9 CORE) (DE698)
108 1-828-954-11 WIRE (FLAT TYPE) (9 CORE) (DE698/DV10)
0 110 1-769-079-23 CORD, POWER (KR)
0 110 1-777-071-23 CORD, POWER (E2)
0 110 1-777-071-83 CORD, POWER (AEP,UK)
0 110 1-783-820-11 CORD, POWER (US,CND)
0 110 1-783-941-12 CORD, POWER (AR)
0 110 1-827-295-22 CORD, POWER (AUS)
0 110 1-827-597-41 CORD, POWER (TW)
0 F901 1-532-464-33 FUSE (T2.5AL/250V) (AEP,UK,AUS,AR,KR)
0 F901 1-532-465-33 FUSE (3.15A/125V) (E2)
0 F901 1-532-504-33 FUSE (4A/250V) (TW)
0 F901 1-533-454-12 FUSE, GLASS TUBE (DIA. 5) (6.3A/125V)
(US,CND)
0 F902 1-532-464-33 FUSE (T2.5AL/250V) (DE698:AEP,UK,E2,AUS)
0 F902 1-533-453-12 FUSE, GLASS TUBE (DIA. 5) (5A/125V)
(DE698:US,CND/DV10)
Q503 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q504 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q533 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q534 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q572 8-729-026-08 TRANSISTOR 2SC4495 (DE698/DV10)
Q603 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q604 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q653 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q654 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q703 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q704 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q753 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q754 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q2573 6-702-390-01 TRANSISTOR MN2488-OPY-MK (DE698/DV10)
Q2754 6-702-391-01 TRANSISTOR MP1620-OPY-MK (DE698/DV10)
0 T901 1-439-550-21 TRANSFORMER, POWER (AEP,UK,AUS,AR,KR)
0 T901 1-439-552-21 TRANSFORMER, POWER (TW)
0 T901 1-439-553-21 TRANSFORMER, POWER (E2)
0 T901 1-439-611-11 TRANSFORMER, POWER (US,CND)
TN1 1-693-675-11 TUNER PACK (ANTENNA) (DE598:US,CND,E2)
TN1 1-693-675-21 TUNER PACK (ANTENNA)
(DE698:US,CND,E2/DV10)
TN1 1-693-676-11 TUNER PACK (ANTENNA) (DE698:AEP,UK)
TN1 1-693-676-21 TUNER PACK (ANTENNA) (DE598:AEP,UK)
TN1 1-693-678-11 TUNER PACK (ANTENNA) (AUS,AR,KR,TW)
*************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
