TA-E9000ES
– 41 – – 42 –
THIS NOTE IS COMMON FOR PRINTED WIRING
BOARDS AND SCHEMATIC DIAGRAMS.
(In addition to this, the necessary note is printed
in each block.)
For schematic diagrams.
Note:
• All capacitors are in µF unless otherwise noted. pF: µµF
50 WV or less are not indicated except for electrolytics
and tantalums.
• All resistors are in Ω and
1
/
4
W or less unless otherwise
specified.
•
¢
: internal component.
• 2 : nonflammable resistor.
• 5 : fusible resistor.
• C : panel designation.
For printed wiring boards.
Note:
• X : parts extracted from the component side
•
®
: Through hole.
•
¢
: internal component.
• b : Pattern of the rear side.
• U : B+ Line.
• V : B– Line.
• H : adjustment for repair.
• Voltages and waveforms are dc with respect to ground in
playback mode.
• Voltages are taken with a VOM (Input impedance 10 MΩ).
Voltage variations may be noted due to normal produc-
tion tolerances.
• Waveforms are taken with a oscilloscope.
Voltage variations may be noted due to normal produc-
tion tolerances.
• Circled numbers refer to waveforms.
• Abbreviation
CND : Canadian model.
AUS : Australian model.
CH : Chinese model.
IC1015 3
qf
qg
qh
qj
WAVEFORMS
– DIGITAL (1/8) SECTION –
IC1004 !∞
IC1004 !¡
IC1004 0
• Indication of transistor
Caution:
Pattern face side: Parts on the pattern face side seen from the
(Side B) pattern face are indicated.
Parts face side: Parts on the parts face side seen from the
(Side A) parts face are indicated.
C
These are omitted
EB
Q
C
These are omitted
EB
Note:
The components identi-
fied by mark ! or dotted
line with mark ! are criti-
cal for safety.
Replace only with part
number specified.
Note:
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro
spécifié.
qk
IC1015 5
IC2015 !•
7
8
9
0
– DIGITAL (2/8) SECTION –
IC2015 qd
IC2015 !¢
IC2015 !§
qa
qs
qd
IC2015 !ª
IC2015 $™
IC2015 #•
ql
w;
wa
– DIGITAL (4/8) SECTION –
IC2005 (ª
IC2005 `⁄‚·
IC2005 `⁄⁄‚
5
6
– DIGITAL (6/8) SECTION –
IC3008 2
IC3002 !§
IC4002 $º
1
2
3
4
– DIGITAL (7/8) SECTION –
IC4001 %¢
IC4001 %£
IC4001 %™
1
2
– DISPLAY SECTION –
IC901 2
IC901 9
6.2 Vp-p
12 MHz
6 Vp-p
3.3 µsec
5 Vp-p
48 KHz
5.2 Vp-p
5 Vp-p
5.5 Vp-p
1.2 µsec
5.8 Vp-p
0.3 µsec
5.5 Vp-p
3 µsec
4.8 Vp-p
0.8 µsec
3.3 Vp-p
150 µsec
3.3 Vp-p
2.3 µsec
4.4 Vp-p
20 MHz
4.2 Vp-p
7.28 MHz
4.6 Vp-p
20 MHz
3.8 Vp-p
0.8 µsec
4.8 Vp-p
4 µsec
3.5 Vp-p
3.6 µsec
3.2 Vp-p
22.5 µsec
4 Vp-p
24.576 MHz
