– 121 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AC3RF
AC INPUT
AC SW ANALOG
R6011 1-216-049-91 RES,CHIP 1K 5% 1/10W
R6012 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R6013 1-216-029-00 METAL CHIP 150 5% 1/10W
R6014 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R6015 1-216-049-91 RES,CHIP 1K 5% 1/10W
R6016 1-216-049-91 RES,CHIP 1K 5% 1/10W
R6017 1-216-049-91 RES,CHIP 1K 5% 1/10W
R6018 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R6019 1-216-049-91 RES,CHIP 1K 5% 1/10W
R6020 1-216-049-91 RES,CHIP 1K 5% 1/10W
R6021 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R6022 1-216-049-91 RES,CHIP 1K 5% 1/10W
R6023 1-216-073-00 METAL CHIP 10K 5% 1/10W
R6024 1-216-049-91 RES,CHIP 1K 5% 1/10W
R6025 1-216-049-91 RES,CHIP 1K 5% 1/10W
R6026 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R6027 1-216-073-00 METAL CHIP 10K 5% 1/10W
R6028 1-216-073-00 METAL CHIP 10K 5% 1/10W
R6029 1-216-093-00 METAL CHIP 68K 5% 1/10W
R6030 1-216-083-00 METAL CHIP 27K 5% 1/10W
R6031 1-216-027-00 METAL CHIP 120 5% 1/10W
R6032 1-216-089-91 RES,CHIP 47K 5% 1/10W
R6033 1-216-089-91 RES,CHIP 47K 5% 1/10W
R6034 1-216-097-91 RES,CHIP 100K 5% 1/10W
R6035 1-216-085-00 METAL CHIP 33K 5% 1/10W
R6036 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R6037 1-216-063-91 RES,CHIP 3.9K 5% 1/10W
R6038 1-216-073-00 METAL CHIP 10K 5% 1/10W
R6039 1-216-073-00 METAL CHIP 10K 5% 1/10W
R6040 1-216-097-91 RES,CHIP 100K 5% 1/10W
R6041 1-216-025-91 RES,CHIP 100 5% 1/10W
R6042 1-216-025-91 RES,CHIP 100 5% 1/10W
R6043 1-216-017-91 RES,CHIP 47 5% 1/10W
R6044 1-216-089-91 RES,CHIP 47K 5% 1/10W
R6045 1-216-089-91 RES,CHIP 47K 5% 1/10W
R6046 1-216-041-00 RES,CHIP 470 5% 1/10W
R6047 1-216-089-91 RES,CHIP 47K 5% 1/10W
R6048 1-216-089-91 RES,CHIP 47K 5% 1/10W
R6049 1-216-073-00 METAL CHIP 10K 5% 1/10W
R6050 1-216-089-91 RES,CHIP 47K 5% 1/10W
R6051 1-216-073-00 METAL CHIP 10K 5% 1/10W
R6053 1-216-089-91 RES,CHIP 47K 5% 1/10W
R6054 1-216-041-00 RES,CHIP 470 5% 1/10W
< VIBRATOR >
X6001 1-767-434-21 VIBRATOR, CRYSTAL (18.432 MHz)
**************************************************************
* 1-671-195-11 AC INPUT BOARD
**************
< CAPACITOR >
! C002 1-113-920-11 CERAMIC 0.0022uF 20% 250V
< CONNECTOR >
CN001 1-564-321-00 PIN, CONNECTOR 2P
* CN003 1-565-792-11 PIN, CONNECTOR 2P
CN006 1-564-321-00 PIN, CONNECTOR 2P
< FUSE >
! F001 1-532-502-51 FUSE (T1.25AL/250V)(EXCEPT US,CND)
! F001 1-576-107-11 FUSE (3.15A/250V)(US,CND)
! F002 1-532-464-51 FUSE (T2.5AL/250V)(EXCEPT US,CND)
! F002 1-576-109-11 FUSE (5A/125V)(US,CND)
< FUSE HOLDER >
FH001 1-533-293-11 FUSE HOLDER
FH002 1-533-293-11 FUSE HOLDER
FH003 1-533-293-11 FUSE HOLDER
FH004 1-533-293-11 FUSE HOLDER
**************************************************************
* 1-671-187-11 AC SW BOARD
***********
< CAPACITOR >
! C001 1-113-920-11 CERAMIC 0.0022uF 20% 250V
< CONNECTOR >
CN002 1-564-321-00 PIN, CONNECTOR 2P
< SWITCH >
S001 1-572-267-21 SWITCH, PUSH (AC POWER)(1 KEY)
(U POWER)
**************************************************************
* A-4417-105-A ANALOG BOARD, COMPLETE (US,CND)
**********************
* A-4417-112-A ANALOG BOARD, COMPLETE (EXCEPT US,CND)
**********************
* 1-535-303-00 WIRE, JUMPER
4-211-649-01 SCREW (+BV 3X6 B)
< CAPACITOR >
C501 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C502 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C503 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C504 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C505 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C506 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C507 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C508 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C509 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C510 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C511 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C512 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C513 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C514 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C515 1-119-823-11 ELECT 4.7uF 20% 50V
C516 1-119-823-11 ELECT 4.7uF 20% 50V
C517 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
