– 120 –
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Abbreviation
CND : Canadian model
• Due to standardization, replacements in the parts list
may be different from the parts specified in the
diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may have
some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
SECTION 6
ELECTRICAL PARTS LIST
Note:
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AC3RF
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque !
sont critiques pour la sécurité.
Ne les remplacer que par une piéce portant
le numéro spécifié.
* A-4417-098-A AC3RF BOARD, COMPLETE
*********************
< CAPACITOR >
C6001 1-126-933-11 ELECT 100uF 20% 16V
C6002 1-126-933-11 ELECT 100uF 20% 16V
C6003 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C6004 1-163-033-91 CERAMIC CHIP 0.022uF 50V
C6005 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C6006 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C6007 1-163-248-11 CERAMIC CHIP 75PF 5% 50V
C6008 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C6009 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C6010 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C6011 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C6012 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C6013 1-136-177-00 FILM 1uF 5% 50V
C6014 1-124-724-11 ELECT 47uF 20% 16V
C6015 1-136-165-00 FILM 0.1uF 5% 50V
C6016 1-136-177-00 FILM 1uF 5% 50V
C6017 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C6018 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C6019 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C6020 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C6021 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C6022 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C6023 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C6024 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C6025 1-126-009-81 ELECT 100uF 20% 16V
C6026 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C6027 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C6028 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C6029 1-163-085-00 CERAMIC CHIP 2PF 50V
C6030 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C6031 1-163-099-00 CERAMIC CHIP 18PF 5% 50V
C6032 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C6033 1-126-048-81 ELECT 10uF 20% 50V
C6034 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C6035 1-163-038-91 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN6001 1-568-439-11 SOCKET, CONNECTOR 7P
< DIODE >
D6001 8-719-061-62 DIODE KV1851
D6002 8-719-801-78 DIODE 1SS184
< FERRITE BEAD >
FB6001 1-410-397-21 FERRITE BEAD INDUCTOR
FB6002 1-410-397-21 FERRITE BEAD INDUCTOR
< FLUORESCENT INDICATOR >
FL6001 1-233-866-11 FILTER, BAND PASS
< IC >
IC6001 8-759-262-03 IC MC14577CF
IC6002 8-759-636-55 IC M5218AFP
IC6003 8-759-463-68 IC SN-PM4007A
IC6004 8-759-476-29 IC N341256SJ-20-TE1
< COIL >
L6001 1-410-391-11 INDUCTOR CHIP 68uH
< TRANSISTOR >
Q6001 8-729-230-49 TRANSISTOR 2SC2712-YG
Q6002 8-729-230-49 TRANSISTOR 2SC2712-YG
Q6003 8-729-230-49 TRANSISTOR 2SC2712-YG
Q6004 8-729-216-22 TRANSISTOR 2SA1162-G
Q6005 8-729-230-49 TRANSISTOR 2SC2712-YG
Q6006 8-729-216-22 TRANSISTOR 2SA1162-G
Q6007 8-729-230-49 TRANSISTOR 2SC2712-YG
Q6008 8-729-230-49 TRANSISTOR 2SC2712-YG
Q6009 8-729-230-49 TRANSISTOR 2SC2712-YG
Q6010 8-729-216-22 TRANSISTOR 2SA1162-G
< RESISTOR >
R6001 1-216-049-91 RES,CHIP 1K 5% 1/10W
R6002 1-216-049-91 RES,CHIP 1K 5% 1/10W
R6003 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R6004 1-216-073-00 METAL CHIP 10K 5% 1/10W
R6005 1-216-073-00 METAL CHIP 10K 5% 1/10W
R6006 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R6007 1-216-024-00 RES,CHIP 91 5% 1/10W
R6008 1-216-043-91 RES,CHIP 560 5% 1/10W
R6009 1-216-049-91 RES,CHIP 1K 5% 1/10W
R6010 1-216-049-91 RES,CHIP 1K 5% 1/10W
When indicating parts by reference
number, please include the board
name.
