41
[D] System Configuration – SYSTEM CONFIGURATION Menu
Chapter 2 Menu
[D11] NETWORK SETTINGS... menu
IP ADDRESS: Set the IP address (default is
“192.168.000.001”).
SUBNET MASK: Set the subnet mask (default is
“255.255.255.000”).
DEFAULT GATEWAY: Set the default gateway on
or off (default setting is OFF).
ADDRESS: Set the default gateway (default is
“---.---.---.--- (no setting)”).
CANCEL: Select to cancel the setting.
CONFIRM: Select to save the setting.
[D2] PARALLEL REMOTE... menu
PARALLEL REMOTE: Select whether or not to use
the PARALLEL REMOTE functions (OFF or ON)
(default setting is OFF)
1 PIN... - 8 PIN...: Assign the function to each pin of
the PARALLEL REMOTE connector when
PARALLEL REMOTE is set to ON. k[D21]
[D21] 1 PIN... - 8 PIN... menu
Assign a function to the selected pin. k[D211]
The factory settings for each pin
1 PIN: CH01
2 PIN: CH02
3 PIN: EXT SYNC
4 PIN: MONO
5 PIN: MARKER
6 PIN: unused
7 PIN: unused
8 PIN: TALLY
[D211] PARALLEL REMOTE menu
PARALLEL REMOTE (1/2) menu
CH01 to 30: Select a channel number. Enter the
desired channel number with the numeric button.
----: Set to unused.
UNDER SCAN: Set under scan on or off.
16:9: Set a 16:9 aspect ratio on or off.
H DELAY: Set the horizontal sync display on or off.
V DELAY: Set the vertical sync display on or off.
EXT SYNC: Set the synchronization to external sync
signals enabled or disabled.
COMB: Set the comb filter on or off.
APERTURE: Set the correction of frequency
characteristics enabled or disabled.
MONO: Set monochrome display on or off.
PARALLEL REMOTE (2/2) menu
BLUE ONLY: Set the blue signal pictures display
(monochrome) on or off.
R OFF: Set cutting red beams enabled or disabled.
G OFF: Set cutting green beams enabled or disabled.
B OFF: Set cutting blue beams enabled or disabled.
CHROMA UP: Set 12 dB up of the chroma setting
value on or off.
MARKER: Set the marker set in the channel on or off.
TALLY: Set tally lamp on or off.
DEGAUSS: Set degaussing on or off.
POWER OFF: Set the monitor power on or standby.
For the pin assignment, see “PARALLEL REMOTE
connector” in Location and Function of Parts on page 15.
[D3] POWER... menu
Set the condition of the monitor when the main power
is turned on or the power is turned on by remote
operation.
STANDBY MODE: Select the power-up condition
(OFF or ON) when the MAIN POWER switch is
turned on.
OFF: Operation mode (default)
ON: Standby mode
POWER ON STATUS: Select the power-up input
channel (LAST or CH).
LAST: Set the channel to the channel that was
selected at the time the power was last turned off
(default).
CH: Set the channel to a specific channel number.
DEFAULT CH: Select the channel (01 to 30) when
the POWER ON STATUS is set to CH. (default
setting is 01)
DEGAUSS DELAY: Set the period from the time
when the picture is almost displayed to the
beginning of degaussing (000 to 255) (default
setting is 000). Enter the desired time (in seconds).
[D4] BLANKING SETTINGS... menu
Adjust the data for the blanking.
ANCILLARY DATA: Select whether or not to
display the ancillary data in the serial digital signal
(OFF or ON) (default setting is ON).
VITS BLK: Adjust vertical blanking so that VITS
signals are not visible in the upper part of the
screen.
Set to 000 to 127 (default setting is 000).
To Next Page
