Specifications
Appendixes
Specifications
General
System 15.625 kHz - 45 kHz (For details, see
“Available Signal Systems” on page
55.)
CRT
HR Trinitron, 4:3 aspect ratio
Aperture grille pitch:
0.25 mm, 90 degree deflection,
Ø29.4 mm diameter in-line gun
Effective picture size
With 16:9 aspect ratio:
267.5 × 150.5 mm (10
5
/8 × 6 inches)
(w/h)
306.9 mm (12
1
/8 inches) (diagonal size)
With 4:3 aspect ratio:
267.5 × 200.6 mm (10
5
/8 × 8 inches)
(w/h)
331.6 mm (13
1
/8 inches) (diagonal size)
CRT protection: EHT (extremely high tension)
protection type
Warm-up time:
approx. 30 minutes
Anode voltage:
25 kV with no beam current
Nominal chromaticity coordinates:
SMPTE C phosphor (BVM-A14F5U)
Error: ± 0.007 or less
EBU phosphor (BVM-A14F5M/A14F5A)
Error: ± 0.007 or less
Power consumption
170 W (When an optional adaptor is
installed)
Power requirements
100 to 240 V AC, 1.8 to 0.8 A,
50/60 Hz
Peak inrush current
1 Power ON, current probe method: 47
A (240 V)
2 Hot switching inrush current,
measured in accordance with
European standard EN55103-1 22 A
(230 V)
Mass approx. 27 kg (59 lb 8 oz)
Input/output connectors
Control
OPTION: Mini-DIN 8-pin (female) × 1
PARALLEL REMOTE: D-sub 9-pin
(female) × 1
SERVICE: D-sub 9-pin (male) × 1
LAN (10BASE-T/100BASE-TX):
RJ-45 × 1
xy
R
0.630 0.340
G
0.310 0.595
B
0.155 0.075
xy
R
0.640 0.330
G
0.290 0.600
B
0.150 0.060
