28
[A] Picture Adjustment – PICTURE ADJ Menu
Chapter 2 Menu
[A] Picture Adjustment
– PICTURE ADJ Menu
Overview
The auto chroma/phase/matrix adjustment and preliminary
adjustment of contrast/brightness/chroma/phase to set the
preset value to each knob are carried out.
• Selecting the preset data to be adjusted (PRESET
VALUE menu)
• Auto chroma/phase/matrix adjustment (AUTO...
menu)
An external color bar signal is necessary.
Matrix data is changed or reset to the default setting.
• Adjustment the preset values for phase/chroma/
brightness/contrast with the MANUAL knobs
(MANUAL ADJUST menu)
• Copying data (COPY FROM... menu)
(available in software version 1.10 or higher)
Other data in the monitor, other monitors or “Memory
Stick” is copied.
Structure of the PICTURE ADJ Menu
Setting Lists in the PICTURE ADJ
Menu
This section explains the setting lists displayed in the
menu.
How to read the setting lists
• For purposes of explanation, each setting list is preceded
by a menu number. These numbers are not displayed on
the screen.
For more information on the menu number, see “About
menu numbers” on page 23.
•The arrow mark (k) refers you to another setting list
that appears after you make the setting, or to an operation
that is to be carried out as a result of the setting.
[A] PICTURE ADJ menu
PRESET VALUE: The picture adjustment preset data
set in the INPUT CONFIGURATION menu is
displayed. To change the picture adjustment preset
data to be adjusted, select from PRESET1,
PRESET2, PRESET3, PRESET4 and PRESET5.
When the picture adjustment preset data is
changed
When the preset data is changed and you press the
MENU button to return to the main menu, the
following message appears to confirm the setting.
CHANGE INPUT CONFIG?
PRESET VALUE
PRESETX (previous preset data) t PRESETX
(new preset data)
OK: Press the ENTER or Ent button to change the
preset data.
The preset data set in the INPUT
CONFIGURATION menu is changed to the new
data.
CANCEL: Press the MENU button to cancel
changing the preset data and to return to the main
menu.
The setting of the preset data is remained but the
data set in the INPUT CONFIGURATION menu is
not changed.
For information about the INPUT
CONFIGURATION menu, see “
[C]
Setting the
Input Configuration – INPUT CONFIGURATION
Menu” on page 34.
AUTO...: Set the chroma/phase/matrix automatically.
k[A1]
Level 1
Level 2
Level 3
PRESET VALUE
AUTO... [A1] AUTO ADJUST [A11]
MATRIX VALUE
MATRIX RESET
COLOR BAR
MANUAL ADJUST
[A2]
COPY FROM... [A3}
(available in software
version 1.10 or
higher)
PRESET VALUE...
[A31]
OTHER MONITOR...
[A32]
OTHER MONITOR
[A321]
MEMORY STICK...
[A33]
MEMORY STICK
[A331]
To Next Page
