26
Menu Structure
Chapter 2 Menu
Menu Structure
The main menu and Level 1 are shown below.
Detailed information on the menu levels is described at the
top of each menu explanation.
Main menu Level 1 Functions
PICTURE ADJ [A] Adjusts the picture. (page 28)
PRESET VALUE Selects the preset data to be adjusted. (page 28)
AUTO [A1] Sets the chroma/phase/matrix automatically. (page 29)
MANUAL ADJUST [A2] Sets the preset values for the phase/chroma/brightness/contrast
with the MANUAL adjustment knob. (page 29)
COPY FROM [A3] Copies the other picture preset data. (page 30)
(available in software version 1.10 or higher)
COLOR TEMP ADJ [B] Adjusts the color temperature. (page 30)
PRESET VALUE Selects the color temperature data to be adjusted. (page 31)
MANUAL [B1] Sets the color temperature with the MANUAL knob. (page 31)
AUTO [B2] Sets the color temperature automatically. (page 32)
COPY FROM [B3] Copies the other color temperature. (page 33)
(available in software version 1.10 or higher)
RESTORE FACTORY DATA [B4] Resets the color temperature. (page 33)
ANALYZE [B5 ] Reads the color temperature and luminance value. (page 33)
INPUT CONFIGURATION [C] Sets the data for the input signals. (page 34)
CHxx Current channel is indicated.(page 35)
FORMAT [C1] Selects the signal format. (page 36)
SLOT NO Selects the slot number. (page 35)
INPUT NO Selects the input connector number. (page 35)
SCREEN ASPECT Sets the aspect ratio. (page 35)
SCAN SIZE Sets the scan size. (page 35)
SYNC MODE Sets the sync signal. (page 35)
COLOR TEMP Selects the color temperature. (page 35)
PICTURE PRESET Selects the picture adjustment preset. (page 36)
MATIRIX [C2] Sets the matrix of the signal system. (page 37)
APERTURE Chooses whether to use aperture adjustment or not. (page 36)
VALUE Enters the aperture adjustment value. (page 36)
YC SEP Selects Y/C separation filter. (page 36)
NTSC COMB FILTER Sets the NTSC COMB ilter. (page 36)
MARKER DISPLAY Chooses whether or not to display the marker. (page 36)
MODE [C3] Sets the marker aspect, safe area, safe title, etc. (page 37)
H PHASE Adjusts the horizontal picture position. (page 36)
CHANNEL NAME [C4] Sets the channel name. (page 38)
COPY FROM [C5] Copies the data from other channel. (page 39)
(available in software version 1.10 or higher)
