36
[C] Setting the Input Configuration – INPUT CONFIGURATION Menu
Chapter 2 Menu
PICTURE PRESET: Select the picture adjustment
preset (PRESET1 to 5). (default setting is
PRESET1)
MATRIX...: Displays the MATRIX menu. Set the
matrix of each signal format. k[C2]
INPUT CONFIGURATION (2/2) menu
APERTURE: Choose whether or not to use aperture
adjustment (OFF, ON, LAST).
OFF: Do not use aperture adjustment (default).
ON: Use aperture adjustment.
LAST: Use the previous setting.
VALUE: Enter the aperture adjustment value (0 to
200) (default setting is 000).
YC SEP: Select Y/C separation filter.
COMB: Use the comb filter (default).
BPF/TRAP: Select BPF/TRAP.
NTSC COMB FILTER: Select the NTSC COMB
FILTER (3 LINES or 3D) (default setting is 3
LINES).
MARKER DISPLAY: Choose whether or not to
display the marker (OFF or ON) (default setting is
OFF).
MODE...: Display the MARKER MODE menu. Set
the marker aspect, safe area, safe title, etc. k[C3]
H PHASE: Set the horizontal picture position (–100 to
+100*) (default setting is 000).
* When the setting value is out of range, the display
is changed but the horizontal position of the picture
is not changed.
CHANNEL NAME...: Display the CHANNEL
NAME menu. Give the channel a name. k[C4]
COPY FROM...: Display the COPY FROM menu.
Copy other channel data. k[C5]
[C1] FORMAT... menu
Select the signal format.
SDI/HD-SDI...: Serial digital signal k[C11]
DUAL LINK HD-SDI...: Dual link HD-SDI signal
k[C12]
COMPOSITE...: Analog composite signal k[C13]
YC...: Analog Y/C signal k[C14]
COMPONENT...: Analog component or RGB signal
k[C15]
If there is no input connector or decoder corresponding to
a format, that format will not be selectable (the cursor will
skip over that item).
[C11] SDI/HD-SDI... menu
Select the serial digital signal format (SDI or single link
HD-SDI).
HD-SDI/D1 AUTO: Select when BKM-62HS is
installed.
HD SDI: Select when BKM-62HS is installed.
D1: Select when BKM-61D or BKM-62HS is
installed.
D1/D2 AUTO: Select when BKM-61D is installed.
D2 NTSC: Select when BKM-61D is installed.
D2 PAL: Select when BKM-61D is installed.
NTSC SETUP LEVEL: Select the NTSC SETUP
LEVEL (0 % or 7.5 %) (default setting is 7.5 % for
BVM-A14F5U, 0 % for BVM-A14F5M/A14F5A).
FILTER SW: Set the Y/C separation filter (OFF or
ON) when the picture is set to black and white
mode (default setting is OFF).
ACC SW: Select the auto chroma control ON or OFF
(default setting is OFF).
1080/60I or 1035/60I is selected automatically for the HD-
SDI 1125/60I input signal.
[C12] DUAL LINK HD-SDI... menu
Select the dual link HD-SDI signal format when BKM-
62HS is installed.
4:4:4 YPBPR
4:4:4 RGB
[C13] COMPOSITE... menu
Select the composite signal format when BKM-61D is
installed.
AUTO: The format of the input signal is detected and
switched automatically.
It will take a few seconds to detect the format of an
input signal. It is recommended that a particular
format be selected if it is determined.
NTSC
PAL
PAL-M
SECAM
NTSC SETUP LEVEL: Select the NTSC SETUP
LEVEL (0 % or 7.5 %) (default setting is 7.5 % for
BVM-A14F5U, 0 % for BVM-A14F5M/A14F5A).
FILTER SW: Set the Y/C separation filter (OFF or
ON) when the picture is set to black and white
mode (default setting is OFF).
ACC SW: Select the auto chroma control ON or OFF
(default setting is OFF).
Note
