37
[C] Setting the Input Configuration – INPUT CONFIGURATION Menu
Chapter 2 Menu
[C14] YC... menu
Select the Y/C signal format when BKM-61D is installed.
AUTO: The format of the input signal is detected and
switched automatically.
It will take a few seconds to detect the format of an
input signal. It is recommended that a particular
format be selected if it is determined.
NTSC
PAL
PAL-M
SECAM
NTSC SETUP LEVEL: Select the NTSC SETUP
LEVEL (0 % or 7.5 %) (default setting is 7.5 % for
BVM-A14F5U, 0 % for BVM-A14F5M/A14F5A).
ACC SW: Select the auto chroma control ON or OFF
(default setting is OFF).
[C15] COMPONENT... menu
Select the component signal format or RGB signal format
(YPBPR or RGB) when BKM-68X is installed.
COMPONENT LEVEL: Select the COMPONENT
LEVEL (SMPTE/EBU-N10 or BETACAM)
(default setting is SMPTE/EBU-N10).
BETACAM SETUP LEVEL: Select the BETACAM
SETUP LEVEL (0 % or 7.5 %) (default setting is
7.5 % for BVM-A14F5U, 0 % for BVM-A14F5M/
A14F5A).
1125/60I SYSTEM: Select the active lines (1080I
(1080 active lines) or 1035I (1035 active lines))
when 1125/60I signal is input (default setting is
1080I).
[C2] MATRIX... menu
Set the matrix for each signal system.
1080/720: Select the matrix data of 1080I and 720P
(default setting is ITU709).
1035: Select the matrix data of 1035I (default setting is
SMPTE 240M).
480/576: Select the matrix data of 480I, 480P, 575I
and 576P (default setting is ITU601).
ITU601, SMPTE 240M, ITU709 or USER1 to 5 is
selectable in each item.
When ITU601, SMPTE 240M or ITU709 data is changed,
they are displayed as ITU601*, SMPTE 240M* or
ITU709*.
When the signal format set in the [C1] FORMAT menu is
4:4:4 RGB or RGB, MATRIX menu is not selectable.
[C3] MODE... menu
Set the marker aspect, safe area, safe title, etc.
If a signal without the sync signal is input or the internal
sync signal is used, this menu is not selectable.
MARKER MODE (1/3) menu
Set the marker aspect mode, aspect marker, blanking, etc.
ASPECT MODE: Set the marker aspect ratio of the
picture.
You can select one from among 16:9, 15:9, 14:9,
13:9, 4:3, 2.39:1, 2.35:1, 1.85:1, 1.66:1 and
VARIABLE (default setting is 16:9).
ASPECT: Set when VARIABLE is selected in
ASPECT MODE.
Set 1.00 to 3.00 (default setting is 1.78).
H POSITION: Set the horizontal position of the
marker.
Set –100 to + 100 (default setting is 000).
MARKER BRIGHT: Set the luminance of the
marker.
Set 90IRE or 40IRE (default setting is 90IRE).
The data set in this menu is common to all the
channels.
ASPECT MARKER: Select whether or not to display
the safe area.
Set to OFF (not display) or ON (display) (default
setting is OFF).
LINE: Set the thickness of the aspect marker when
ASPECT MARKER is set to ON.
Set to THICK or THIN (default setting is THICK).
COLOR: Set the color of the aspect marker when
ASPECT MARKER is set to ON.
Set to WHITE, RED, GREEN, BLUE, YELLOW,
CYAN or MAGENTA (default setting is WHITE).
ASPECT BLANKING: Select the blanking outside
the area.
Set to OFF (blanking is released) or ON (blanking)
(default setting is OFF).
MODE: Set the blanking mode when ASPECT
BLANKING is set to ON.
Set BLACK (blanking) or HALF (half blanking)
(default setting is HALF).
Note
To Next Page
