[C] Setting the Input Configuration – INPUT CONFIGURATION Menu
Chapter 2 Menu
When FORMAT... is set to the following, you cannot select
the input number.
– when BKM-61D is installed and Analog Y/C signal is
input
– when BKM-62HS is installed and Dual Link HD-SDI
signal is input
– when BKM-68X is installed and Analog Component
or Analog RGB signal is input
Structure of the INPUT
CONFIGURATION Menu
Setting Lists in the INPUT
CONFIGURATION Menu
This section explains the setting lists displayed in the
menu.
How to read the setting lists
• For purposes of explanation, each setting list is preceded
by a menu number. These numbers are not displayed on
the screen.
For more information on the menu number, see “About
menu numbers” on page 23.
• The arrow mark (k) refers you to another setting list
that appears after you make the setting, or to an operation
that is to be carried out as a result of the setting.
[C] INPUT CONFIGURATION menu
This menu is composed by the INPUT
CONFIGURATION (1/2) and INPUT
CONFIGURATION (2/2) menus.
Set input signal data for each channel.
INPUT CONFIGURATION (1/2) menu
CHxx: Current channel is indicated. The settings
below will be stored as information about the signal
to be connected to this channel.
FORMAT...: Select the input signal type. k[C1]
SLOT NO: Enter the option slot number (OPTION1 to
3).
INPUT NO: Enter the input connector number.
SCREEN ASPECT: Select the aspect ratio (16:9, 4:3,
LAST).
16:9: Set the aspect ratio to 16:9 (default).
4:3: Set the aspect ratio to 4:3.
LAST: Use the previous setting.
SCAN SIZE...: Select the scan size (NORMAL,
UNDER, LAST).
NORMAL: Set the scan size to over scan (default).
UNDER: Set the scan size to under scan.
LAST: Use the previous setting.
SYNC MODE: Select the sync signal (INT, EXT,
LAST).
INT: Use an internal sync signal (default).
EXT: Use an external sync signal.
LAST: Use the previous setting.
COLOR TEMP: Select the color temperature (D93,
D65, D61 or USER1 to 5).
When D93, D65 or D61 data is changed, they are
displayed as D93*, D65* or D61*.
Notes
Level 1 Level 2 Level 3
CHxx
FORMAT... [C1] SDI/HD-SDI... [C11]
DUAL LINK HD-SDI...
[C12]
COMPOSITE... [C13]
YC... [C14]
COMPONENT... [C15]
SLOT NO
INPUT NO
SCREEN ASPECT
SCAN SIZE
SYNC MODE
COLOR TEMP
PICTURE PRESET
MATRIX... [C2]
APERTURE
VALUE
YC SEP
NTSC COMB FILTER
MARKER DISPLAY
MODE... [C3]
H PHASE
CHANNEL NAME...
[C4]
COPY FROM... [C5]
(available in software
version 1.10 or
higher)
OTHER CH... [C51]
OTHER MONITOR...
[C52]
OTHER MONITOR
[C521]
MEMORY STICK...
[C53]
MEMORY STICK
[C531]
To Next Page
