27
Menu Structure
Chapter 2 Menu
SYSTEM CONFIGURATION [D] Sets the system of the remote control function, LAN, etc. (page
39)
NETWORK [D1] Sets the IP address, subnet mask and default gateway. (page 40)
PARALLEL REMOTE [D2] Sets the remote control function. (page 41)
POWER [D3] Sets the condition of the monitor when the main power or I/1
switch is turned on. (page 41)
BLANKING SETTINGS [D4] Adjusts the data for the picture. (page 41)
ON SCREEN SET [D5] Sets the data for the screen display. (page 42)
PASSWORD [D6] Sets the passwords for the menu. (page 42)
MAINTENANCE [D7] Displays the menu for maintenance. (page 42)
INSTALLATION SETTINGS [E] Sets the initial value of landing, alignment, etc. (page 43)
LANDING ADJUST [E1] Corrects the shift of beam landing caused by the earth’s
magnetism. (page 44)
ALIGNMENT [E2] Adjusts the position and size of the picture. (page 44)
DIGITAL UNIFORMITY ADJ [E3] Adjusts the color unevenness of the CRT. (page 45)
FILE MANAGEMENT [F] Saves, copies and deletes the system data. (page 47)
SAVE TO [F1] Writes the data. (page 48) (available in software version 1.10 or
higher)
COPY FROM [F2] Reads or copies the data. (page 48) (available in software version
1.10 or higher)
DELETE [F3] Deletes the file. (page 48) (available in software version 1.10 or
higher)
DATA MAINTENANCE [F4] Services the system data. (page 48)
STATUS [G] Displays the information about the monitor or options installed in
the monitor. (page 49)
CH STATUS [G1] Displays the information of the used channel. (page 50)
SLOT STATUS [G2] Displays the data about the optional board installed in the option
slot 1 to 3. (page 50)
MODEL NAME Displays the model name. (page 50)
SERIAL NO Displays the serial number. (page 50)
SOFTWARE VERSION Displays the software version. (page 50)
OPERATION TIME Displays the operation time. (page 50)
CRT TURN ON TIME Displays how long the CRT is used. (page 50)
IP ADDR Displays the IP address of the monitor. (page 50)
CONTROLLER STATUS [G 3] Displays the information on the controller (controlled moitor).
(page 50)
CONTROLLER [H] When the Monitor Control Unit BKM-15R is connected, sets the
network of the controller. (page 51)
MONITOR ID DISPLAY [H1] Sets the display method of the monitor select display window.
(page 51)
NETWORK SETTING [H2] Displays the NETWORK SETTING menu. (page 51)
NETWORK SW Sets the Ethernet connections. (page 51)
KEY PROTECT [I] Sets whether or not to lock the buttons on the monitor. (page 52)
Main menu Level 1 Functions
To Next Page
