仕様
60
 付録
外形寸法図
単位 :mm
上面
前面
右側面
左側面
背面
426
8.5
482
340
280
265
15
131.5
28
500
378
370
90
ø30
43
28
500
185
370
90
ø30
43
28
340
4268.5
