Sony VPL-ES5 - GAMMA Service Tool Application Software

1-10
VPL-ES5/EX5/EX50/EX5U/EW5
1-3-11. 3D GAMMA Service tool Application Software
Feature of 3D Gamma Quick Access :
. It can read 3D gamma data from a set and save it in a file.
. It can write 3D gamma data in a PC into a set.
When the optical unit is replaced, load 3D gamma data recorded on the micro floppy disk, which is
supplied together with the optical unit, into a set using the application software.
File configuration :
Executable : Ernie Service tool.exe
Readme File : readme_j.txt (Japanese)
readme_e.txt (English)
Software Acquisition :
Download the application software from the GSP website.
. VPL-ES5 set has not RS-232C terminal, use the PCBA MOTOR TEST BD E08S MI.
. Remove the rubber cap on the upper left of the rear side of the unit.
J12
Set
Main board CN
CN 5P
CN J8
5pin
Dsub
9pin
(Parts No. 9-885-122-51)
RS-232C
Straight
cable
PC
PCBA MOTOR TEST BD E08S MI
PCBA MOTOR
TEST BD E08S MI
