1-1
VPL-ES5/EX5/EX50/EX5U/EW5
1-1. Appearance Figure
1-2. Board Locations
Section 1
Service Overview
Main
Door detection switch
Thermal sensor
Door detection switch
IR sensor
Power
Lamp power supply
