1-2
VPL-ES5/EX5/EX50/EX5U/EW5
1-3. Disassembly
1-3-1. Upper Case Assembly
!-
Upper case assembly
4
Screw
(+P M3 x 6)
2 Loosen screw.
3
Lamp door assembly
5
Two claws
6
Remove the filter
door in the direction
of the arrow
C
.
C
B
B
Front Side
of Unit
These portions are fragile.
Be very careful not to
damage them.
1
Five screws
(+P M3 x 6)
7
Screw
(+P M3 x 6)
A
B
Caution :
If the spacings in the top and bottom are not equal, go to
“Assembling
method of optical unit assembly and Focus/Zoom
adjust assembly”.
(Refer to section 1-3-8. Steps 9 to 14.)
Upon completion of the upper
case assembly attachment,
check to see that the spacing
in the top is equal to the
spacing in the bottom.
Focus adjust gear knob
8
Press here strongly.
9
Remove the Upper case assembly
in the direction of the arrow.
Caution :
Remove the upper case assembly from this corner.
When attaching the upper case assembly, attach it while
aligning with the lower case assembly starting from this corner.
0
Disengage the claws at
the 17 locations respectively.
Upper case assembly
Lower case assembly
Front Side
of Unit
A
A
AA
A
B
B
Lower case assembly
To Next Page
