34
VPLL-CW10
SS 60 80 100 120 150 180 200 250 300
N
1728 2331 2934 3536 4440 5344 5947 7454 8961
a (68
1
/
8
) (91
3
/
4
) (115
3
/
8
) (139
1
/
2
) (174
7
/
8
) (210
3
/
8
) (234
3
/
8
) (293
3
/
8
) (352
7
/
8
)
M
2094 2819 3543 4267 5353 6439 7163 8974 10784
(82
3
/
8
) (111
1
/
8
) (139
1
/
2
) (168
1
/
4
) (210
3
/
4
) (253
5
/
8
) (282) (353
1
/
4
) (424
1
/
2
)
b
c+71.7
(2
7
/
8
)
x
c+529 c+681 c+834 c+986 c+1215 c+1443 c+1596 c+1977 c+2358
(20
7
/
8
) (26
7
/
8
) (32
7
/
8
) (38
7
/
8
) (47
7
/
8
) (56
7
/
8
) (62
7
/
8
) (77
7
/
8
) (92
7
/
8
)
Unit: mm (inches)
Standard lens
SS 40 60 80 100 120 150 180 200 250 300
N
1458 2217 2977 3736 4495 5635 6774 7533 9432 11330
a (57
1
/
2
) (87
1
/
2
) (117
3
/
8
) (147
3
/
8
) (177
1
/
4
) (221
3
/
4
) (266
5
/
8
) (296
1
/
2
) (371
3
/
8
) (446
1
/
8
)
M
1764 2675 3586 4497 5408 6774 8141 9052 11329 13607
(69
3
/
8
) (105
1
/
4
) (141
3
/
8
) (177
1
/
4
) (213
1
/
8
) (266
5
/
8
) (320
5
/
8
) (356
3
/
8
) (446
1
/
8
) (536)
b
c+71.7
(2
7
/
8
)
x
c+377 c+529 c+681 c+834 c+986 c+1215 c+1443 c+1596 c+1977 c+2358
(14
7
/
8
) (20
7
/
8
) (26
7
/
8
) (32
7
/
8
) (38
7
/
8
) (47
7
/
8
) (56
7
/
8
) (62
7
/
8
) (77
7
/
8
) (92
7
/
8
)
a (N) = {(SS × 33.60/0.9071) – 59.7012} × 1.025
a (M) = {(SS × 42.376846/0.9071) – 59.62151} × 0.975
x = c + (SS/0.9071 × 6.912 + 71.7)
VPL-PX15/PX10
VPLL-CT10
SS 40 60 80 100
a
2176 3370 4567 5757
(85
7
/
8
) (132
3
/
4
) (179
5
/
8
) (226
7
/
8
)
b
c+71.7
(2
7
/
8
)
x
c+377 c+529 c+681 c+834
(14
7
/
8
) (20
7
/
8
) (26
7
/
8
) (32
7
/
8
)
a = (SS × 54.15/0.9071) – 211.9761
x = c + (SS/0.9071 × 6.912 + 71.7)
When you use the VPLL-CT10, set the screen size between
40 to 100 inches.
a (N) = {(SS × 26.67/0.9071) – 78} × 1.025
a (M) = {(SS × 33.6858/0.9071) – 80.10359} × 0.975
x = c + (SS/0.9071 × 6.912+71.7)
When you use the VPLL-CW10, set the screen size
between 60 to 300 inches.
English
Ceiling Installation
This section describes the examples for installing the
projector on the ceiling. B
When installing the projector on the ceiling, use the PSS-
610 Projector Suspension Support.
For ceiling installation, ask for qualified Sony personnel
only.
See the charts on pages 34 and 35 concerning the
installation measurements.
The alphabetical letters in the illustration indicate the
distances below.
a : distance between the screen and the center of the lens
b : distance between the ceiling and the center of the lens
c : distance between the ceiling and the surface of the
mounting bracket
x : distance between the ceiling and the center of the screen
Ceiling
Distance between the front of the cabinet and
the center of the lens
Wall
B
Center of the screen
Center of the lens
PSS-610 Projector Suspension Support (not supplied)
Standard / ±Í◊º : –25.4 (–1)
VPLL-CT10: +51.0 (+2
1
/
8
)
VPLL-CW10: +67.1 (+2
3
/
4
)
Unit: mm (inches)
To Next Page
