29
VPLL-CW10
SS 60 80 100 120 150 180 200 250 300
N
1731 2335 2939 3543 4448 5354 5958 7467 8977
a (68
1
/
8
) (92
1
/
4
) (115
7
/
8
) (139
1
/
2
) (175
1
/
4
) (210
3
/
4
) (234
3
/
4
) (294
1
/
4
) (353
5
/
8
)
M
2098 2824 3549 4274 5363 6451 7176 8990 10803
(82
3
/
4
) (111
1
/
8
) (139
7
/
8
) (168
1
/
4
) (211
1
/
8
) (254) (282
3
/
4
) (354) (425
1
/
4
)
b
x-458 x-611 x-763 x-916 x-1145 x-1374 x-1527 x-1908 x-2290
(18
1
/
8
) (24
1
/
8
) (30
1
/
8
) (36
1
/
8
) (45
1
/
8
) (54
1
/
8
) (60
1
/
8
) (75
1
/
4
) (90
1
/
4
)
c
x-541 x-694 x-847 x-999 x-1228 x-1457 x-1610 x-1992 x-2373
(21
3
/
8
) (27
3
/
8
) (33
3
/
8
) (39
3
/
8
) (48
3
/
8
) (57
3
/
8
) (63
1
/
2
) (78
1
/
2
) (93
1
/
2
)
VPLL-CT10
SS 40 60 80 100
a
2179 3375 4571 5767
(85
7
/
8
) (133
1
/
8
) (180) (227
1
/
4
)
b
x-305 x-458 x-611 x-763
(12
1
/
8
) (18
1
/
8
) (24
1
/
8
) (30
1
/
8
)
c
x-389 x-541 x-694 x-847
(15
3
/
8
) (21
3
/
8
) (27
3
/
8
) (33
3
/
8
)
Unit: mm (inches)
VPL-PS10
a = (SS × 54.15/0.9055) – 213
b = x – (SS/0.9055 × 6.912)
c = x – (SS/0.9055 × 6.912 + 83.4)
When you use the VPLL-CT10, set the screen size between
40 to 100 inches.
a (N) = {(SS × 26.67/0.9055) – 78.2988048} × 1.025
a (M) = {(SS × 33.685039/0.9055) – 80} × 0.975
b = x – (SS/0.9055 × 6.912)
c = x – (SS/0.9055 × 6.912 + 83.4)
When you use the VPLL-CW10, set the screen size
between 60 to 300 inches.
30
English
Installation Diagram
Floor Installation
The installation measurements and their calculation method
for each lens are shown on pages 28 and 29.
The alphabetical letters in the charts and calculation
methods indicate the following.
SS : screen size measured diagonally (inches)
a : distance between the screen and the center of the lens
b : distance between the floor and the center of the lens
c : distance between the floor and the bottom of the
adjusters of the projector
x : free
N : minimum
M : maximum
