28
VPLL-CT10
SS 40 60 80 100
a
2176 3370 4567 5757
(85
7
/
8
) (132
3
/
4
) (179
5
/
8
) (226
7
/
8
)
b
x-305 x-457 x-610 x-762
(12) (18) (24) (30)
c
x-388 x-541 x-693 x-845
(15
3
/
8
) (21
3
/
8
) (27
3
/
8
) (33
3
/
8
)
a (N) = {(SS × 26.67/0.9071) – 78} × 1.025
a (M) = {(SS × 33.6858/0.9071) – 80.10359} × 0.975
b = x – (SS/0.9071 × 6.912)
c = x – (SS/0.9071 × 6.912 + 83.4)
When you use the VPLL-CW10, set the screen size
between 60 to 300 inches.
Unit: mm (inches)
VPLL-CW10
SS 60 80 100 120 150 180 200 250 300
N
1728 2331 2934 3536 4440 5344 5947 7454 8961
a (68
1
/
8
) (91
3
/
4
) (115
3
/
8
) (139
1
/
2
) (174
7
/
8
) (210
3
/
8
) (234
3
/
8
) (293
3
/
8
) (352
7
/
8
)
M
2094 2819 3543 4267 5353 6439 7163 8974 10784
(82
3
/
8
) (111
1
/
8
) (139
1
/
2
) (168
1
/
4
) (210
3
/
4
) (253
5
/
8
) (282) (353
1
/
4
) (424
1
/
2
)
b
x-457 x-610 x-762 x-914 x-1143 x-1372 x-1524 x-1905 x-2286
(18) (24) (30) (36) (45) (54) (60) (75
1
/
8
) (90
1
/
8
)
c
x-541 x-693 x-845 x-998 x-1226 x-1455 x-1607 x-1988 x-2369
(21
3
/
8
) (27
3
/
8
) (33
3
/
8
) (39
3
/
8
) (48
3
/
8
) (57
3
/
8
) (63
3
/
8
) (78
3
/
8
) (93
3
/
8
)
a = (SS × 54.15/0.9071) – 211.9761
b = x – (SS/0.9071 × 6.912)
c = x – (SS/0.9071 × 6.912 + 83.4)
When you use the VPLL-CT10, set the screen size between
40 to 100 inches.
VPL-PX15/PX10
Distance between the front of the cabinet and
the center of the lens
Unit: mm (inches)
Floor
Wall
A
Center of the screen
Center of the lens
English
Installation Diagram
Floor Installation
This section describes the examples for installing the
projector on the desk, etc. A
See the charts on pages 28 and 29 concerning the
installation measurements.
When using the standard lens, refer to the operating
instructions.
The alphabetical letters in the illustration indicate the
distances below.
a : distance between the screen and the center of the lens
b : distance between the floor and the center of the lens
c : distance between the floor and the bottom of the
adjusters of the projector
x : free
Standard / ±Í◊º : –25.4 (–1)
VPLL-CT10: +51.0 (+2
1
/
8
)
VPLL-CW10: +67.1 (+2
3
/
4
)
