1-4. VPLL-CW10 Operating Instructions
4-084-806-01 (1)
Projection Lens
Operating Instructions Manual de instrucciones
Mode d’emploi Istruzioni per l
’uso
Bedienungsanleitung
VPLL-CW10
Sony Corporation © 2001 Printed in Japan
English
The VPLL-CW10 Projection Lens is a short focal length
converter lens designed for use with the Sony VPL-PX15/
PX10/PS10, etc LCD Data Projector.
About lens attachment
Attaching the lens may cause injury to the person.
Users should request qualified Sony representative to attach
the lens.
Notes on lens attachment
•
The lens scratches easily. When handling the lens, always place
it gently on a stable, level surface in a horizontal position.
• Avoid touching the lens surface.
Specifications
Short Focal Length Converter Lens
F=1.9 to 2.1 f=26.8 to 33.5 mm
(1
1
/
16
to 1
3
/
8
inches)
Projection picture size 60 to 300 inches
Throwing distance (when
100 inches: 2934 to 3543 mm
using VPL-PX15/PX10) (115
3
/
8
to 139
1
/
2
inches)
200 inches: 5947 to 7163 mm
(234
3
/
8
to 282 inches)
300 inches: 8961 to 10784 mm
(352
7
/
8
to 424
1
/
2
inches)
Throwing distance (when
100 inches: 2939 to 3549 mm
using VPL-PS10) (115
7
/
8
to 139
7
/
8
inches)
200 inches: 5958 to 7176 mm
(234
3
/
4
to 282
3
/
4
inches)
300 inches: 8977 to 10803 mm
(353
5
/
8
to 425
1
/
4
inches)
Dimensions 116 × 116 × 78.5 mm
(4
1
/
2
× 4
1
/
2
× 3
1
/
6
inches) (w/h/d)
Mass 1130 g (2 lb 8 oz)
Supplied accessories Operating Instructions (1)
Screw (1)
Design and specifications are subject to change without notice.
installation manual.
