1-5. VPLL-CT10 Operating Instructions
4-084-808-01 (1)
Projection Lens
Operating Instructions Manual de instrucciones
Mode d’emploi Istruzioni per l
’uso
Bedienungsanleitung
VPLL-CT10
Sony Corporation © 2001 Printed in Japan
English
The VPLL-CT10 Projection Lens is a long focal length
converter lens designed for use with the Sony VPL-PX15/
PX10/PS10, etc LCD Data Projector.
About lens attachment
Attaching the lens may cause injury to the person.
Users should request qualified Sony representative to attach
the lens.
Notes on lens attachment
• The lens scratches easily. When handling the lens, always
place it gently on a stable, level surface in a horizontal
position.
• Avoid touching the lens surface.
• When you use the VPLL-CT10, set the standard lens of the
projector to the long focus position to prevent vignetting (a
fall-off in brightness at the edges of the image).
Specifications
Long Focal Length Converter Lens
F=2.2 f=53.5 mm (2
1
/
8
inches)
Projection picture size 40 to 100 inches
Throwing distance (when 40 inches: 2176 mm (85
7
/
8
inches)
using VPL-PX15/PX10) 80 inches: 4567 mm (179
5
/
8
inches)
100 inches: 5757 mm (226
7
/
8
inches)
Throwing distance (when 40 inches: 2179 mm (85
7
/
8
inches)
(when using VPL-PS10) 80 inches: 4571 mm (180 inches)
100 inches: 5767 mm (227
1
/
4
inches)
Dimensions 136 × 136 × 104.5 mm
(5
3
/
8
× 5
3
/
8
× 4
1
/
8
inches) (w/h/d)
Mass 1110 g (2 lb 7 oz)
Supplied accessories Operating Instructions (1)
Screw (1)
Design and specifications are subject to change without notice.
installation manual.
