2-2

VPL-VW10HT

2-2. Cabinet Assy Removal

2-3. Front Panel Assy Removal

3 Two screws (+B3 x 6)

4 Two screws (+B3 x 6)

5 Two screws (+B3 x 6)

CN7001

6 Cabinet assy

1 Push in claw

Driver _

2 Lens cover (TP)

2 Lens cover (BT)

CN5008

4 Front panel assy

3 Two screws (+B3 x 6)

1 Two screws (+BVTP3 x 8)
