Sony VPL-VW10HT Service Manual

6-1
VPL-VW10HT
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
* A-1131-492-A BM MOUNT
**********************
<CAPACITOR>
C1001 1-107-884-11 ELECT 1000µF 20% 16V
C1002 1-107-884-11 ELECT 1000µF 20% 16V
<CONNECTOR>
CN1001 * 1-779-004-11 HOUSING, CONNECTOR 26P
CN1002 * 1-779-004-11 HOUSING, CONNECTOR 26P
CN1003 * 1-779-004-11 HOUSING, CONNECTOR 26P
CN1004 * 1-779-004-11 HOUSING, CONNECTOR 26P
CN1005 * 1-779-004-11 HOUSING, CONNECTOR 26P
CN1006 * 1-564-523-11 PLUG, CONNECTOR 8P
CN1007 * 1-564-526-11 PLUG, CONNECTOR 11P
CN1008 * 1-564-521-11 PLUG, CONNECTOR 6P
CN1009 1-695-915-11 TAB (CONTACT)
CN1010 * 1-564-505-11 PLUG, CONNECTOR 2P
<RESISTOR>
R1001 1-216-379-21 METAL OXIDE 6.8 5% 2W F
*************************************************************
* A-1136-046-A B COMPL
**********************
<CAPACITOR>
C3001 1-117-681-11 ELECT CHIP 100µF 20% 16V
C3002 1-117-681-11 ELECT CHIP 100µF 20% 16V
C3003 1-117-681-11 ELECT CHIP 100µF 20% 16V
C3004 1-117-681-11 ELECT CHIP 100µF 20% 16V
C3006 1-117-681-11 ELECT CHIP 100µF 20% 16V
C3007 1-126-204-11 ELECT CHIP 47µF 20% 16V
C3008 1-126-204-11 ELECT CHIP 47µF 20% 16V
C3009 1-126-204-11 ELECT CHIP 47µF 20% 16V
C3011 1-117-681-11 ELECT CHIP 100µF 20% 16V
C3012 1-128-008-11 ELECT CHIP 3.3µF 20% 35V
C3013 1-117-681-11 ELECT CHIP 100µF 20% 16V
C3014 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3015 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C3016 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C3017 1-107-682-11 CERAMIC CHIP 1µF 10% 16V
C3018 1-163-037-11 CERAMIC CHIP 0.022µF 10% 50V
C3020 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C3021 1-107-682-11 CERAMIC CHIP 1µF 10% 16V
C3022 1-126-601-11 ELECT CHIP 2.2µF 20% 50V
C3023 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C3024 1-117-681-11 ELECT CHIP 100µF 20% 16V
C3025 1-117-681-11 ELECT CHIP 100µF 20% 16V
C3026 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C3027 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C3028 1-127-820-91 CERAMIC CHIP 4.7µF 0 16V
C3029 1-117-681-11 ELECT CHIP 100µF 20% 16V
C3030 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3031 1-163-227-11 CERAMIC CHIP 10pF 0.5pF 50V
C3032 1-128-004-11 ELECT CHIP 10µF 20% 16V
C3033 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3034 1-125-898-91 CERAMIC CHIP 0.22µF 10% 50V
C3035 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C3036 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C3038 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C3039 1-107-682-11 CERAMIC CHIP 1µF 10% 16V
C3040 1-107-682-11 CERAMIC CHIP 1µF 10% 16V
C3041 1-107-682-11 CERAMIC CHIP 1µF 10% 16V
C3042 1-127-820-91 CERAMIC 4.7µF 0 16V
C3043 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3044 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3045 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3046 1-126-204-11 ELECT CHIP 47µF 20% 16V
C3047 1-126-204-11 ELECT CHIP 47µF 20% 16V
C3048 1-126-204-11 ELECT CHIP 47µF 20% 16V
C3049 1-128-004-11 ELECT CHIP 10µF 20% 16V
C3050 1-128-004-11 ELECT CHIP 10µF 20% 16V
C3051 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C3052 1-117-681-11 ELECT CHIP 100µF 20% 16V
C3053 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3054 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3055 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3056 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C3057 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C3059 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3060 1-126-205-11 ELECT CHIP 47µF 20% 6.3V
C3061 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3062 1-128-004-11 ELECT CHIP 10µF 20% 16V
C3063 1-126-205-11 ELECT CHIP 47µF 20% 6.3V
BM
Section 6
Electrical Parts List
B
The components identified marked ! are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque !
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
NOTE :
• Items marked “ * ” are not stocked since they are seldom required
for routine service. Some delay should be anticipated when order-
ing these items.
• Due to standardization, replacements in the parts list may be dif-
ferent from the parts specified in the diagrams or the components
used on the set.
RESISTORS
• All resistors are in ohms.
• F: nonflammable
• METAL: Metal-film resistor
• METAL OXIDE: Metal oxide-film resistor
