Sony VPL-VW10HT Service Manual

6-2
VPL-VW10HT
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
C3064 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3065 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3066 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3067 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3068 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3069 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3070 1-117-681-11 ELECT CHIP 100µF 20% 16V
C3071 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3072 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3073 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3074 1-126-205-11 ELECT CHIP 47µF 20% 6.3V
C3075 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C3076 1-163-237-11 CERAMIC CHIP 27pF 5% 50V
C3077 1-163-237-11 CERAMIC CHIP 27pF 5% 50V
C3078 1-163-245-11 CERAMIC CHIP 56pF 5% 50V
C3079 1-163-245-11 CERAMIC CHIP 56pF 5% 50V
C3080 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C3081 1-128-004-11 ELECT CHIP 10µF 20% 16V
C3082 1-126-204-11 ELECT CHIP 47µF 20% 16V
C3084 1-163-235-11 CERAMIC CHIP 22pF 5% 50V
C3085 1-163-245-11 CERAMIC CHIP 56pF 5% 50V
C3086 1-163-235-11 CERAMIC CHIP 22pF 5% 50V
C3087 1-117-681-11 ELECT CHIP 100µF 20% 16V
C3088 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3089 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3090 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3091 1-163-131-00 CERAMIC CHIP 390pF 5% 50V
C3092 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V
C3093 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3094 1-163-229-11 CERAMIC CHIP 12pF 5% 50V
C3095 1-163-229-11 CERAMIC CHIP 12pF 5% 50V
C3096 1-163-229-11 CERAMIC CHIP 12pF 5% 50V
C3097 1-163-229-11 CERAMIC CHIP 12pF 5% 50V
C3098 1-117-681-11 ELECT CHIP 100µF 20% 16V
C3099 1-117-681-11 ELECT CHIP 100µF 20% 16V
C3100 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3101 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3102 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3103 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3104 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3105 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3108 1-128-013-11 ELECT CHIP 1µF 20% 50V
C3111 1-117-681-11 ELECT CHIP 100µF 20% 16V
C3112 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3113 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3114 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3115 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3116 1-128-007-11 ELECT CHIP 2.2µF 20% 35V
C3117 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C3118 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3119 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3120 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3122 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3123 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3124 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3125 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3126 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3127 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3128 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V
C3129 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3130 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3133 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3135 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3136 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3137 1-117-681-11 ELECT CHIP 100µF 20% 16V
C3138 1-128-396-11 ELECT CHIP 470µF 20% 10V
C3139 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C3140 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3141 1-117-681-11 ELECT CHIP 100µF 20% 16V
C3143 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3144 1-117-681-11 ELECT CHIP 100µF 20% 16V
C3145 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C3147 1-128-004-11 ELECT CHIP 10µF 20% 16V
C3149 1-163-133-00 CERAMIC CHIP 470pF 5% 50V
C3150 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3151 1-128-013-11 ELECT CHIP 1µF 20% 50V
C3152 1-117-681-11 ELECT CHIP 100µF 20% 16V
C3153 1-163-227-11 CERAMIC CHIP 10pF 0.5pF 50V
C3154 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C3155 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C3156 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C3157 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3158 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3159 1-117-681-11 ELECT CHIP 100µF 20% 16V
C3160 1-117-681-11 ELECT CHIP 100µF 20% 16V
C3161 1-117-681-11 ELECT CHIP 100µF 20% 16V
C3162 1-117-681-11 ELECT CHIP 100µF 20% 16V
C3163 1-128-004-11 ELECT CHIP 10µF 20% 16V
<CONNECTOR>
CN3001 * 1-778-373-11 PIN, CONNECTOR (PC BOARD) 26P
CN3002 * 1-778-373-11 PIN, CONNECTOR (PC BOARD) 26P
<DIODE>
D3001 8-719-914-43 DIODE DAN202K
<FERRITE BEAD>
FB3001 1-414-753-91 INDUCTOR 4.7µH
FB3002 1-543-775-11 FERRITE 0µH
FB3003 1-543-775-11 FERRITE 0µH
FB3004 1-543-775-11 FERRITE 0µH
FB3005 1-414-753-91 INDUCTOR 4.7µH
FB3006 1-414-753-91 INDUCTOR 4.7µH
FB3007 1-414-234-22 INDUCTOR CHIP 0µH
FB3008 1-414-234-22 INDUCTOR CHIP 0µH
FB3009 1-414-234-22 INDUCTOR CHIP 0µH
FB3010 1-414-234-22 INDUCTOR CHIP 0µH
<FILTER>
FL3001 1-233-736-21 FILTER, EMI
FL3002 1-233-736-21 FILTER, EMI
FL3003 1-233-736-21 FILTER, EMI
FL3004 1-233-736-21 FILTER, EMI
FL3005 1-233-736-21 FILTER, EMI
FL3006 1-233-736-21 FILTER, EMI
FL3007 1-239-289-11 FILTER, LOW PASS
FL3008 1-239-289-11 FILTER, LOW PASS
FL3009 1-239-847-11 FILTER, LOW PASS
<IC>
IC3001 8-759-460-72 IC BA033FP-E2
IC3002 8-759-460-74 IC BA05FP-E2
IC3004 8-759-460-74 IC BA05FP-E2
IC3005 * 8-759-524-25 IC TC7WH241FU(TE12R)
IC3006 8-752-094-47 IC CXA2123AQ-T6
IC3007 8-759-353-02 IC NJM2533M(TE2)
IC3008 8-759-353-02 IC NJM2533M(TE2)
IC3010 8-759-436-89 IC MC141627FT
IC3011 8-759-269-92 IC SN74HCU04ANSR
IC3012 8-759-568-27 IC MSM514265C-60JSDR1
B
