Sony VPL-VW10HT Service Manual

6-5
VPL-VW10HT
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
C2501 ! 1-113-912-11 CERAMIC 0.0047µF 20% 250V
C2502 ! 1-107-533-11 FILM 1µF 20% 275V
C2503 ! 1-109-835-11 FILM 0.68µF 20% 275V
C2504 ! 1-113-912-11 CERAMIC 0.0047µF 20% 250V
C2505 ! 1-113-912-11 CERAMIC 0.0047µF 20% 250V
<CONNECTOR>
CN2501 * 1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
CN2502 1-695-915-11 TAB (CONTACT)
CN2503 * 1-691-960-21 PIN, CONNECTOR (PC BOARD) 3P
<FUSE>
F2500 ! 1-576-233-11 FUSE (H.B.C.) (63A/250V)
1-533-223-11 HOLDER, FUSE; F2500
<COIL>
L2500 ! 1-415-967-11 INDUCTOR 5mH
<RESISTOR>
R2500 ! 1-202-847-00 SOLID 560K 20% 1/2W
R2501 ! 1-202-847-00 SOLID 560K 20% 1/2W
<VARISTOR>
VD2500 ! 1-801-073-41 VARISTOR ERZV14D471
*************************************************************
A-1275-185-A Q COMPL
**********************
<CAPACITOR>
C4001 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C4002 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C4003 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C4004 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C4005 1-163-133-00 CERAMIC CHIP 470pF 5% 50V
C4006 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C4007 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C4008 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C4009 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C4010 1-109-994-11 CERAMIC CHIP 2.2µF 10% 10V
C4011 1-109-994-11 CERAMIC CHIP 2.2µF 10% 10V
C4012 1-124-779-00 ELECT CHIP 10µF 20% 16V
C4013 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4014 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4015 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4016 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4017 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4018 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4019 1-126-204-11 ELECT CHIP 47µF 20% 16V
C4020 1-126-204-11 ELECT CHIP 47µF 20% 16V
C4021 1-126-204-11 ELECT CHIP 47µF 20% 16V
C4022 1-163-245-11 CERAMIC CHIP 56pF 5% 50V
C4023 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4024 1-117-681-11 ELECT CHIP 100µF 20% 16V
C4025 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4026 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4027 1-117-681-11 ELECT CHIP 100µF 20% 16V
C4028 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4029 1-128-453-21 ELECT CHIP 47µF 20% 6.3V
C4030 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4031 1-128-453-21 ELECT CHIP 47µF 20% 6.3V
C4032 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4033 1-128-453-21 ELECT CHIP 47µF 20% 6.3V
C4034 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4035 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4040 1-104-601-11 ELECT CHIP 10µF 20% 10V
C4041 1-126-205-11 ELECT CHIP 47µF 20% 6.3V
C4042 1-104-601-11 ELECT CHIP 10µF 20% 10V
C4043 1-126-204-11 ELECT CHIP 47µF 20% 16V
C4044 1-164-344-11 CERAMIC CHIP 0.068µF 10% 25V
C4045 1-124-779-00 ELECT CHIP 10µF 20% 16V
C4046 1-124-779-00 ELECT CHIP 10µF 20% 16V
C4047 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4048 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4049 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4050 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C4051 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C4052 1-126-205-11 ELECT CHIP 47µF 20% 6.3V
C4053 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4054 1-117-681-11 ELECT CHIP 100µF 20% 16V
C4055 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4056 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C4058 1-117-681-11 ELECT CHIP 100µF 20% 16V
C4059 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4060 1-124-778-00 ELECT CHIP 22µF 20% 6.3V
C4061 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C4063 1-126-205-11 ELECT CHIP 47µF 20% 6.3V
C4064 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4065 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4066 1-126-204-11 ELECT CHIP 47µF 20% 16V
C4067 1-126-204-11 ELECT CHIP 47µF 20% 16V
C4068 1-126-204-11 ELECT CHIP 47µF 20% 16V
C4069 1-163-131-00 CERAMIC CHIP 390pF 5% 50V
C4070 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C4071 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4072 1-117-681-11 ELECT CHIP 100µF 20% 16V
C4073 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4074 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4075 1-128-008-11 ELECT CHIP 3.3µF 20% 35V
C4079 1-126-204-11 ELECT CHIP 47µF 20% 16V
C4080 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4082 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4083 1-126-204-11 ELECT CHIP 47µF 20% 16V
C4084 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4085 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C4086 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C4087 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C4088 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C4089 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C4090 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C4091 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C4092 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C4093 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C4094 1-126-204-11 ELECT CHIP 47µF 20% 16V
C4095 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4098 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C4099 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C4100 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C4101 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C4102 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C4103 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C4104 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C4105 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C4106 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
