Sony VPL-VW10HT Service Manual

6-7
VPL-VW10HT
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
C4246 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4247 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4248 1-117-681-11 ELECT CHIP 100µF 20% 16V
C4249 1-128-006-11 ELECT CHIP 4.7µF 20% 25V
C4250 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4251 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C4252 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4253 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4254 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4255 1-117-681-11 ELECT CHIP 100µF 20% 16V
C4256 1-117-681-11 ELECT CHIP 100µF 20% 16V
C4257 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4258 1-126-204-11 ELECT CHIP 47µF 20% 16V
C4259 1-126-205-11 ELECT CHIP 47µF 20% 6.3V
C4260 1-126-205-11 ELECT CHIP 47µF 20% 6.3V
C4261 1-126-205-11 ELECT CHIP 47µF 20% 6.3V
C4262 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4263 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4264 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4268 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4269 1-128-004-11 ELECT CHIP 10µF 20% 16V
C4270 1-128-013-11 ELECT CHIP 1µF 20% 50V
C4271 1-128-004-11 ELECT CHIP 10µF 20% 16V
C4272 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4273 1-126-395-11 ELECT CHIP 22µF 20% 16V
C4274 1-126-395-11 ELECT CHIP 22µF 20% 16V
C4275 1-128-013-11 ELECT CHIP 1µF 20% 50V
C4276 1-126-395-11 ELECT CHIP 22µF 20% 16V
C4277 1-128-004-11 ELECT CHIP 10µF 20% 16V
C4278 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4281 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4282 1-128-004-11 ELECT CHIP 10µF 20% 16V
C4283 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C4284 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C4285 1-126-603-11 ELECT CHIP 4.7µF 20% 35V
C4286 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
<CONNECTOR>
CN4001 1-537-797-12 TERMINAL BOARD ASSY, I/O
(REMOTE (RS-232C))
CN4002 * 1-793-797-21 CONNECTOR, BOARD TO BOARD 50P
CN4003 * 1-778-373-11 PIN, CONNECTOR (PC BOARD) 26P
CN4004 * 1-785-305-21 CONNECTOR, BOARD TO BOARD 70P
CN4005 * 1-778-373-11 PIN, CONNECTOR (PC BOARD) 26P
CN4006 * 1-778-373-11 PIN, CONNECTOR (PC BOARD) 26P
<DIODE>
D4001 8-719-037-22 DIODE RD12SB-T1
D4002 8-719-158-37 DIODE RD9.1SB2
D4003 8-719-914-43 DIODE DAN202K
D4004 8-719-914-43 DIODE DAN202K
D4005 8-719-914-44 DIODE DAP202K
D4006 8-719-037-53 DIODE RD27SB-T1
D4007 8-719-914-42 DIODE DA204K
D4008 8-719-037-53 DIODE RD27SB-T1
D4009 8-719-037-53 DIODE RD27SB-T1
D4010 8-719-914-42 DIODE DA204K
D4011 8-719-037-53 DIODE RD27SB-T1
D4012 8-719-158-37 DIODE RD9.1SB2
D4013 8-719-158-37 DIODE RD9.1SB2
D4014 8-719-158-37 DIODE RD9.1SB2
D4015 8-719-800-76 DIODE 1SS226
D4016 8-719-800-76 DIODE 1SS226
D4017 8-719-800-76 DIODE 1SS226
D4018 8-719-800-76 DIODE 1SS226
D4019 8-719-800-76 DIODE 1SS226
D4021 8-719-914-43 DIODE DAN202K
D4022 8-719-914-43 DIODE DAN202K
D4023 8-719-914-43 DIODE DAN202K
D4024 8-719-422-12 DIODE MA8039
D4032 8-719-914-43 DIODE DAN202K
D4033 8-719-914-43 DIODE DAN202K
D4034 8-719-914-43 DIODE DAN202K
<FILTER>
FL4001 1-234-346-21 FILTER, LOW PASS
FL4002 1-234-346-21 FILTER, LOW PASS
FL4003 1-234-345-21 FILTER, LOW PASS
FL4004 1-234-344-21 FILTER, LOW PASS
FL4005 1-234-344-21 FILTER, LOW PASS
FL4006 1-234-343-21 FILTER, LOW PASS
<IC>
IC4001 8-759-285-61 IC PC74HC123D-T
IC4002 8-759-252-59 IC MAX202CSE
IC4003 8-759-457-53 IC GS1881-CTA
IC4004 8-752-072-94 IC CXA1875AM-T4
IC4005 8-752-072-94 IC CXA1875AM-T4
IC4006 8-759-646-02 IC M52347FP-TE
IC4007 8-759-491-93 IC EL4332CS-TE2
IC4008 8-759-186-43 IC TC74VHC123AF
IC4009 8-759-174-16 IC TC74VHC244F
IC4010 * 8-759-524-24 IC TC7WT241FU(TE12R)
IC4011 8-759-038-15 IC MC74HC4538AF
IC4012 8-759-344-12 IC GS4981CTA
IC4013 8-752-086-33 IC CXA2101AQ-TL
IC4014 8-759-433-92 IC TC7W14F-TE12L
IC4015 8-759-460-72 IC BA033FP-E2
IC4016 8-759-460-74 IC BA05FP-E2
IC4017 8-759-460-81 IC BA12FP-E2
IC4018 8-759-539-89 IC LM2990SX-5.0
IC4020 8-759-460-79 IC BA09FP-E2
IC4021 8-759-988-13 IC LM393PS
IC4022 8-759-353-02 IC NJM2533M(TE2)
IC4023 8-759-988-13 IC LM393PS
IC4024 8-759-353-02 IC NJM2533M(TE2)
IC4025 8-759-353-02 IC NJM2533M(TE2)
IC4026 8-759-988-13 IC LM393PS
IC4027 8-759-353-02 IC NJM2533M(TE2)
IC4028 8-759-460-72 IC BA033FP-E2
IC4029 8-759-447-90 IC TLC5733AIPM
IC4030 8-752-072-94 IC CXA1875AM-T4
IC4031 8-759-430-32 IC TLC2933IPWR
IC4032 8-749-015-18 IC PQ07VZ012P
IC4033 8-752-398-47 IC CXD2090Q
IC4034 8-759-295-09 IC TLC2932IPW
IC4035 8-759-573-19 IC MSM56V16160D-10TS-K
IC4036 8-759-700-78 IC NJM082M
IC4038 8-759-092-82 IC SN75157PS-ELL2000
IC4039 8-759-031-84 IC SC7S04F
<JACK>
J4001 1-563-935-11 JACK, STEREO HEADPHONE
(TRIGGER)
J4002 1-563-935-11 JACK, STEREO HEADPHONE
(CONTROLS-IN)
Q
