Sony VPL-VW10HT Service Manual

6-20
VPL-VW10HT
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
R5433 1-216-864-11 SHORT 0
R5434 1-216-864-11 SHORT 0
R5435 1-216-864-11 SHORT 0
R5436 1-216-864-11 SHORT 0
R5471 1-216-815-11 RES,CHIP 330 5% 1/16W
R5472 1-216-815-11 RES,CHIP 330 5% 1/16W
R5473 1-216-809-11 RES,CHIP 100 5% 1/16W
R5474 1-216-833-91 RES,CHIP 10K 5% 1/16W
R5475 1-216-839-11 RES,CHIP 33K 5% 1/16W
R5476 1-216-809-11 RES,CHIP 100 5% 1/16W
R5477 1-216-864-11 SHORT 0
R5501 1-216-864-11 SHORT 0
R5502 1-216-864-11 SHORT 0
R5503 1-216-864-11 SHORT 0
R5504 1-216-864-11 SHORT 0
R5505 1-216-864-11 SHORT 0
R5506 1-216-864-11 SHORT 0
R5507 1-218-665-11 METAL CHIP 75 0.50% 1/16W
R5508 1-218-665-11 METAL CHIP 75 0.50% 1/16W
R5509 1-218-665-11 METAL CHIP 75 0.50% 1/16W
R5510 1-218-665-11 METAL CHIP 75 0.50% 1/16W
R5511 1-218-665-11 METAL CHIP 75 0.50% 1/16W
R5512 1-218-665-11 METAL CHIP 75 0.50% 1/16W
R5513 1-216-864-11 SHORT 0
R5514 1-216-864-11 SHORT 0
R5515 1-218-672-11 METAL CHIP 150 0.50% 1/16W
R5516 1-218-672-11 METAL CHIP 150 0.50% 1/16W
R5517 1-218-672-11 METAL CHIP 150 0.50% 1/16W
R5518 1-218-672-11 METAL CHIP 150 0.50% 1/16W
R5519 1-218-672-11 METAL CHIP 150 0.50% 1/16W
R5520 1-218-672-11 METAL CHIP 150 0.50% 1/16W
R5525 1-216-809-11 RES,CHIP 100 5% 1/16W
R5526 1-216-809-11 RES,CHIP 100 5% 1/16W
R5527 1-216-809-11 RES,CHIP 100 5% 1/16W
R5528 1-216-809-11 RES,CHIP 100 5% 1/16W
R5529 1-216-817-11 RES,CHIP 470 5% 1/16W
R5530 1-216-817-11 RES,CHIP 470 5% 1/16W
R5531 1-216-817-11 RES,CHIP 470 5% 1/16W
R5532 1-216-817-11 RES,CHIP 470 5% 1/16W
R5533 1-216-817-11 RES,CHIP 470 5% 1/16W
R5534 1-216-817-11 RES,CHIP 470 5% 1/16W
R5541 1-216-841-11 RES,CHIP 47K 5% 1/16W
R5542 1-216-853-11 RES,CHIP 470K 5% 1/16W
R5543 1-216-808-11 RES,CHIP 82 5% 1/16W
R5544 1-216-808-11 RES,CHIP 82 5% 1/16W
R5545 1-216-808-11 RES,CHIP 82 5% 1/16W
R5546 1-216-841-11 RES,CHIP 47K 5% 1/16W
R5547 1-216-853-11 RES,CHIP 470K 5% 1/16W
R5548 1-216-809-11 RES,CHIP 100 5% 1/16W
R5549 1-216-809-11 RES,CHIP 100 5% 1/16W
R5550 1-216-808-11 RES,CHIP 82 5% 1/16W
R5552 1-216-809-11 RES,CHIP 100 5% 1/16W
R5554 1-216-809-11 RES,CHIP 100 5% 1/16W
R5555 1-216-809-11 RES,CHIP 100 5% 1/16W
R5556 1-216-809-11 RES,CHIP 100 5% 1/16W
R5557 1-216-809-11 RES,CHIP 100 5% 1/16W
R5558 1-216-809-11 RES,CHIP 100 5% 1/16W
R5559 1-216-809-11 RES,CHIP 100 5% 1/16W
R5560 1-216-809-11 RES,CHIP 100 5% 1/16W
R5561 1-216-809-11 RES,CHIP 100 5% 1/16W
R5562 1-216-817-11 RES,CHIP 470 5% 1/16W
R5564 1-216-057-00 RES,CHIP 2.2K 5% 1/16W
R5565 1-216-057-00 RES,CHIP 2.2K 5% 1/16W
R5566 1-216-817-11 RES,CHIP 470 5% 1/16W
R5568 1-216-057-00 RES,CHIP 2.2K 5% 1/16W
R5569 1-216-057-00 RES,CHIP 2.2K 5% 1/16W
R5570 1-216-817-11 RES,CHIP 470 5% 1/16W
R5572 1-216-057-00 RES,CHIP 2.2K 5% 1/16W
R5573 1-216-057-00 RES,CHIP 2.2K 5% 1/16W
R5574 1-216-833-91 RES,CHIP 10K 5% 1/16W
R5575 1-216-817-11 RES,CHIP 470 5% 1/16W
R5577 1-216-057-00 RES,CHIP 2.2K 5% 1/16W
R5578 1-216-057-00 RES,CHIP 2.2K 5% 1/16W
R5579 1-216-817-11 RES,CHIP 470 5% 1/16W
R5581 1-216-057-00 RES,CHIP 2.2K 5% 1/16W
R5582 1-216-057-00 RES,CHIP 2.2K 5% 1/16W
R5583 1-216-817-11 RES,CHIP 470 5% 1/16W
R5585 1-216-057-00 RES,CHIP 2.2K 5% 1/16W
R5586 1-216-057-00 RES,CHIP 2.2K 5% 1/16W
R5587 1-216-833-91 RES,CHIP 10K 5% 1/16W
R5601 1-216-864-11 SHORT 0
R5603 1-216-864-11 SHORT 0
R5604 1-216-864-11 SHORT 0
R5605 1-216-864-11 SHORT 0
R5607 1-218-271-11 RES,CHIP 2K 5% 1/16W
R5608 1-216-864-11 SHORT 0
R5609 1-216-864-11 SHORT 0
R5612 1-216-864-11 SHORT 0
R5613 1-216-864-11 SHORT 0
R5614 1-218-271-11 RES,CHIP 2K 5% 1/16W
R5615 1-218-271-11 RES,CHIP 2K 5% 1/16W
R5617 1-216-828-11 RES,CHIP 3.9K 5% 1/16W
R5618 1-216-828-11 RES,CHIP 3.9K 5% 1/16W
R5619 1-216-805-11 RES,CHIP 47 5% 1/16W
R5620 1-216-805-11 RES,CHIP 47 5% 1/16W
R5621 1-218-271-11 RES,CHIP 2K 5% 1/16W
R5622 1-216-828-11 RES,CHIP 3.9K 5% 1/16W
R5623 1-216-828-11 RES,CHIP 3.9K 5% 1/16W
R5630 1-216-864-11 SHORT 0
R5631 1-216-864-11 SHORT 0
R5632 1-216-864-11 SHORT 0
R5633 1-216-864-11 SHORT 0
R5634 1-216-864-11 SHORT 0
R5635 1-216-864-11 SHORT 0
R5636 1-216-864-11 SHORT 0
R5637 1-216-864-11 SHORT 0
R5638 1-216-864-11 SHORT 0
R5639 1-216-864-11 SHORT 0
R5640 1-216-864-11 SHORT 0
R5641 1-216-864-11 SHORT 0
R5642 1-216-864-11 SHORT 0
R5643 1-216-809-11 RES,CHIP 100 5% 1/16W
R5644 1-216-825-11 RES,CHIP 2.2K 5% 1/16W
R5645 1-216-809-11 RES,CHIP 100 5% 1/16W
R5646 1-216-825-11 RES,CHIP 2.2K 5% 1/16W
R5647 1-216-825-11 RES,CHIP 2.2K 5% 1/16W
R5648 1-216-825-11 RES,CHIP 2.2K 5% 1/16W
R5649 1-216-789-11 RES,CHIP 2.2 5% 1/16W
R5650 1-216-789-11 RES,CHIP 2.2 5% 1/16W
R5651 1-216-812-11 RES,CHIP 180 5% 1/16W
R5652 1-216-789-11 RES,CHIP 2.2 5% 1/16W
R5653 1-216-789-11 RES,CHIP 2.2 5% 1/16W
R5654 1-216-812-11 RES,CHIP 180 5% 1/16W
R5656 1-216-864-11 SHORT 0
R5657 1-216-864-11 SHORT 0
R5658 1-216-864-11 SHORT 0
R5659 1-216-864-11 SHORT 0
R5660 1-216-864-11 SHORT 0
R5661 1-216-864-11 SHORT 0
R5662 1-216-864-11 SHORT 0
R5663 1-216-864-11 SHORT 0
R5664 1-216-864-11 SHORT 0
