Sound Devices 833 User Manual

Virtual Keyboard
Action
Function
Rotate HP
Scrolls orange highlight through the keyboard characters.
Press HP
Inserts the highlighted character in text field.
‘abc’ switch
Quick flick toggles between A-Z and a-z in keyboard.
Hold ‘abc’ switch
Momentary selection of other case.
Delete
Deletes character to the left of flashing cursor.
Hold Delete
Repeatedly deletes characters to the left of flashing cursor.
Space
Inserts space at the flashing cursor position.
833 User Guide 16

Sound Devices 833 Specifications

General

Number of Channels	8
Mic Inputs	6
Main Outputs	2
Aux Outputs	4
Headphone Output	1
Bit Depth	24-bit
Timecode	Yes
Dynamic Range	120 dB
Microphone Preamps	6
Analog Outputs	4
Type	Portable Mixer-Recorder
Line Inputs	6
AES Inputs	2
Sampling Rate	up to 192 kHz
Recording Media	SD, SDHC, SDXC
Power	Battery or External DC
Frequency Response	10 Hz to 80 kHz
THD+N	0.005%
Digital Outputs	2
