Buses
Selects routing for Buses L,R and 1-4. Access buses via Menu > Buses or by holding Select and toggling a PFL switch.
When a bus screen is entered, that bus is solo’d by default in both HP L and HP R. If the bus is linked, the odd bus will be heard in
HP L and the even bus in HP R. Toggle between Solo and the current HP preset by pressing the HP encoder.
1. 1. Bus Meter
Audio level meter for the selected bus.
2. Link *-*
Selects linking for two odd-to-even numbered adjacent buses. Links bus Gain, bus limiters, Mute Coms, and Mute All
functions.
3. ISO
Any ISO channel contributes to Bus mix. Green fill in text box = Pre-fade, Orange fill in text box = Post-fade, Light Blue fill
in text box = Send gain] Send adjusts the Iso channel send gain to the bus when the selected Iso channel is routed as a
‘Send’ to that bus (light blue fill in text box). When the selected Iso channel is set to ‘Send’ (light blue fill), enter the Send
field with the * toggle then adjust send gain by rotating the HP knob.
Tip: Recorded ISOs can be played back via buses. This is useful for playing back alternate ISO mixes on set. By routing
the ISOs as bus sends instead of pre or post-fader, you can adjust the ISO mix on playback. Use Buses B3-B4 for this
purpose since Bus L, R, B1, and B2 can be recorded and are reserved for playing back their own recorded audio.
