Toggles between Select and HP knob press on 833
Emulates Tone toggle on 833
Emulates ** toggle on 833
Display Ch. Fader Gains
Selects whether the fader gains are displayed in the controller’s display. [Off, On*]
Applies to CL-16 and 3rd party controllers.
Soft Fader/Trim Pickup
[Off*, On] When enabled, physical faders and trims on the 8-Series front panel, CL-16, CL-12, and 3rd party controllers with
non-motorized faders resume gain control only when their physical position reaches the last stored gain value. This prevents sudden
jumps in gain levels when setting gains from more than one control interface.
Note: Last stored gain values are held over a power cycle and may require the adjustment of a physical fader or trim control to
pickup the last stored gain value.
Note: Soft Fader/Trim Pickup also works in conjunction with the SD-Remote. The 8-Series trim/faders pickup control only once they
have reached the last gain set in SD-Remote.
When Soft Fader/Trim Pickup is Off and a controller is connected, the 8-Series front panel controls are disabled unless controlled by
SD-Remote. Use SD-Remote Hide Faders function to prevent SD-Remote changing fader gains accidentally.
Note: When a non-motorized fader controller and SD-Remote are both used at the same time, the controller will not soft pickup fader
or trim control.
CL-16
Selects CL-16 menu.
1. LED Brightness: 5-100% in increments of 5% (100% is default)
2. LCD Brightness: 5-100% in increments of 5% (100% is default)
3. Long Button Press: 300-1000 ms in increments of 5 ms (500 ms is default)
4. Bank Disable: On or Off (off is default)
5. GPIO Configuration: Opens menu to display GPIO_1 - GPIO_8 (see below for options and details)
6. Channel Colors: Opens a menu to assign background colors to LCD channel strips 1-32.
7. Group Colors: Opens menu to assign Group 1-4 Color (Defaults: 1=Yellow, 2=Orange, 3=Light Blue, 4=Light Green).
Color options: Yellow, Orange, Light Blue, Light Green, Green, Light Brown, Brown, Violet, Pink.
CL-16 Operation is covered in the CL-16 User Guide.
CL-16 GPIO (General Purpose Input/Output)
The 10-pin Phoenix connector labeled Remote provides eight GPIO ports. These can be used as simple contact-closure inputs, and
to drive LEDs or relays.
CL-16 Remote Pin Functions
Ground (-) - for triggering logic-low connections.
1 - 8 - Configurable as inputs or outputs, activate high or low, and assigned a function.
+5 V DC - for triggering logic high connections.
Active High inputs trigger when +5V is applied.
Active Low inputs trigger when ground is applied.
Active High outputs go to 5 V when the mapped function is active.
Active Low outputs go to ground when the mapped function is active.
GPIO Outputs can be used to drive LEDs with a proper series resistor. Resistor values vary from LED to LED, 470 ohms is a good
starting point.
