Scorpio User Guide
52
All MCU controllers have custom-mappable buttons for performing any of the following actions on Scorpio:
Function Action
Add Q-mark Adds a Q-mark during record, playback, scrub or pause
Auto Mixer On/Off Toggles the Auto Mixer on/off
Bus Mode Bus Masters
Channel Groups Edit Create/Edit channel groups
Channel Sends on Faders Shortcut to put Bus sends on linear faders/toggle on/off
Channel Source Edit Patch input to channel
Circle Take Circle take
Com Send 1 Activates Com Send 1
Com Send 1 (Latch) Activates Com Send 1 latching operation
Com Send 1 (Momentary) Activates Com Send 1 momentary operation
Com Send 2 Activates Com Send 2
Com Send 2 (Latch) Activates Com Send 2 latching operation
Com Send 2 (Momentary) Activates Com Send 2 momentary operation
Com Rtn 1 Activates Com Rtn 1
Com Rtn 2 Activates Com Rtn 2
Create Sound Report Creates Sound Report to selected media
Dante Out Edit Shortcut to Dante Output Routing screen
Delete Q-mark Deletes a Q-mark during record, playback, scrub or pause
Edit Scene Name Edits the current scene name
Edit Take Notes Edits the notes for the current take
Edit Take Number Edits the number for the current take
EQ Mode Spills EQ parameters over scribble strips, Fader Bank right to view last parameter.
Push and hold V-Pot 1 to toggle EQ on/off, push each band’s amplitude V-Pot to toggle
on/off each band, push each band’s Q V-Pot to toggle EQ type Shelf/Peak.
Fader Bank Left Switches faders to left banks on connected controller
Fader Bank Right Switches faders to right banks on connected controller
False Take Activates False Take function
Fast Fwd Press and hold to fast forward during playback
Fat Ch. Mode Spills fat channel parameters across scribble strips
Fat Ch. Mode Bus Spills fat channel bus parameters across scribble strips
Fav HP Preset Recalls Fav HP Preset from Main Menu>Outputs>HP Presets
Fav Toggle Emulates Fav toggle on Scorpio
Home Activates Home screen and Trim knobs mode
HP Presets Menu Shortcut to Main Menu>Outputs>HP Presets
Jog is HP Switches Jog wheel to emulate HP knob on Scorpio
Jog is Select Switches Jog wheel to emulate Select knob on Scorpio
Jog Wheel Press Acts as “Select” while using jog wheel
L-ident Identies left channel output by varying amplitude vs. right channel with constant amplitude
LR Returns Meter Activates the returns meter view
Menu Emulates the Menu button on Scorpio
Meter Emulates the Meter button on Scorpio
Mic Toggle Emulates the Mic toggle on Scorpio
Mix Low Cut Mode Activates all V-Pots to Low Cut mode on every channel. Push to reset to O Hz.
Mix Pan Mode Activates all V-Pots to Pan mode on every channel. Push to center pan
Mix Trim Mode Activates all V-Pots to Trim mode on every channel. Push to enter pan mode.
Nav Down Moves the highlighted selection up one in matrix screens, emulates HP knob down in Home screen
Nav Left Navigates back to previous screen
Nav Right Selects the currently highlighted selection
