Scorpio User Guide
51
Supported Third-party Controllers
Scorpio supports some third-party external controllers that conform to
the MCU protocol. Two controllers may be connected simultaneously
for extended control. The CL-12 Linear Fader Controller cannot be
used with another control surface.
SONOSAX SX-LC8+ Eight channel compact fader bank with faders
and channel selects for channels 1-8 plus controls for slate mic,
record, and stop. The Mic, Rec, and Stop buttons are mappable to
other functions using the Mapping menu.*Only one LC8+ can be
connected.
Ensure the Sonosax is set to USB Midi mode
1. Press and hold buttons 6 + 7 + 8 and connect the USB cable to the
8-Series USB-A port. The mode change is conrmed by a blinking REC
2. Reboot the 8-series.
ICON PLATFORM M+ AND D2 DISPLAY Eight channel fader bank
with control over gain, bus, sends, coms, trim and pan. Dedicated
Select, Mute, Solo and Arm buttons for each channel. Bank switch to
access Scorpio channels 1-32 in four banks of eight channels.
ICON PLATFORM X+ Eight channel expansion fader bank with
single assignable knob and Select, Mute, Solo and Arm buttons.
ICON PLATFORM B+ Assignable illuminated 50 pad button surface.
Connects via USB-A cable, not mini DIN.
BEHRINGER X-TOUCH Eight channel trim and fader panel with
master volume and additional mappable buttons. Bank switch to
access Scorpio channels 1-32 in four banks of eight channels.
MACKIE MCU PRO Eight channel trim and fader panel with master
volume and additional mappable buttons. Bank switch to access
Scorpio channels 1-32 in four banks of eight channels.
