SPE EXPERT 1.3K-FA - Kenwood; CAT RS232 Interface; CAT 5 V TTL Interface

User manual
Expert Amp 1.3K-FA
Page. 36 of 87
12.3 Kenwood
CAT RS232 Interface
4
3
2
1
5
6
7
8
9
12
13
14
11
10
15
GND
GND
RADIO CONNECTOR
DB15 M
RX 232
TX 232
RX 232
TX 232
.
RTS
CTS
(RXD)
(TXD)
The Radio connector could be DB-9 or DB-25 male connector or female connector
(read the specific manual). In the manual, also verify if the RTS–CTS link is necessary.
CAT 5V TTL Interface
4
3
2
1
5
6
7
8
9
12
13
14
11
10
15
GND
GND
RADIO CONNECTOR
RX
TX
DB15 M
RX TTL
TX TTL
KEN TTL
RTS
CTS
.
The connector is described in the transceiver’s manual.
Verify if the RTS–CTS link is required by the transceiver.
