Introduction:
The LiterMeter 4 is a programmable pump controller that controls up
to four dosing pumps (12VDC), individually and simultaneously. Ideally,
the pumps will be SpectraPure’s Peristaltic Dosing Pumps, but any small
12VDC pump can be used. A 12VDC/1A power supply is included and is
able to power all four SpectraPure pumps at once.
The LiterMeter 4 (LM4) may be laid flat on a shelf, set on its back, or Velcroed
to a wall or under a shelf. It can be orientated with the wires at the top or
at the bottom of the unit. When the orientation of the LM4 changes and
after a button is pressed, the display will flip so that it is readable, and the
5 buttons operate in the new orientation.
Functions are grouped in pages as “Settings”, “Calibrate”, “System”, and
“Inputs”. All parameters are updated and saved as soon as a button is
pressed. There is no need for an extra “do it” or “save it now” button.
A personal device (PD) such as a smartphone, tablet, PC or Mac may also
be used to control the LM4.
Settings:
Each pump can operate independently in one of several Modes: Off, On,
Daily, Dose, Once, Timer, or Delay.
Calibrate:
Easy-to-Follow Calibration Procedure using included 100 ml. graduated
cylinder.
System:
General settings including Inputs, Networks, and Calibrations.
