ATO + Water Exchange + Kalk System:
This is a 4-Pumps + 4-Inputs example demonstrating the
comprehensive water level control possible with the LM4.
Parts List:
1x LM4 & Power Supply
4x Pumps
3x Sensors
1x Wet Floor Sensor (available soon)
8x EXT Cables, Length as Required
8x Tubing, 1/4”, Length as Required
Plumbing Connections:
Connect tubing from DI Water to Pump “A”.
Connect tubing from Pump “A” to sump.
Connect tubing from Fresh Salt Water to Pump “B”.
Connect tubing from Pump “B” to sump.
Connect tubing from sump (position end 2” below normal
sump level) to Pump “C”.
Connect tubing from Pump “C” to drain.
Connect tubing from Kalkwasser to Pump “D”.
Connect tubing from Pump “D” to sump.
Electrical Connections:
Follow the diagram.
Sub-systems have been described previously.
Inputs Settings:
If Input#1(Fresh Salt Water) is DRY, then “B” & “C” are OFF
If Input#2(Wet Floor Sensor) is WET, then ALL PUMPS OFF
If Input#3(Normal Sump Level) is WET, then “A” is OFF
If Input#4(Critical Sump Level) is WET, then ALL PUMPS OFF
EXT Cables are available in 3 ft, 6 ft, 12 ft, and 25 ft lengths.
