SPEKTRUM DX9 • TRANSMITTER INSTRUCTION MANUAL
EN
Spoken Flight Mode Setup
Enables you to assign custom names to the Flight Mode positions.
Flight Mode names can include up to 20 characters including
spaces.
To change the Flight Mode name:
1. Scroll to the Flight Mode name you wish to change and press
the scroll wheel.
2. Scroll to the character position you wish to change and press
thescrollwheelonce.Aashingboxappears.
3. Scroll left or right until the desired character appears. Press
the scroll wheel once to save the character.
4. Repeat Steps 2 and 3 until the Model Name is complete.
5.SelectBACKtoreturntotheFlightModeNameslist.
Spoken Flight Mode:
The Spoken Flight Mode option enables you to activate audio flight
mode alerts. As you change between flight modes, the transmitter
will “speak”, informing you of the active flight mode. You can
select a word or phrase for each flight mode.
To activate Spoken Flight Mode:
1. Enter the Spoken Flight Mode menu option.
2. Scroll to <Silence> (default), then press the scroll wheel.
3. Scroll left or right to view the options.
4. Press the scroll wheel again to save the selection.
F-Mode Setup
Use the Flight Mode Setup menu to assign switches to
flight modes.
Sailplane Flight Mode Setup
You can assign up to ten flight modes using any combination of
up to three switches. You can also assign a priority switch. When
the priority switch position is active, only the current flight mode is
active, regardless of other switch positions.
Aircraft and Sailplane Flight Mode Table
You can assign the available flight modes (up to 5 for Air, up to 10 for
Sail) to each of the switch positions (up to 3 switches can be used for
sailplane and up to 2 switches can be used for aircraft). Press NEXT
from the Flight Mode Name page to access the flight mode table
assignmentpagewhenCustomightmodehasbeenselectedinthe
Flight Mode Setup page. The combination of up to 2 or 3 switches can
be used to access all of the flight modes available.
Mode Number of Switches Number of Flight Modes
Aircraft 2 5
Heli 3 (including Throttle Hold) 5 (including Throttle Hold)
Number
of Flight
Modes
2 3 3* 4 4 5
Switch 1
(number of
positions)
2P 3P 2P 2P 3P 3P
Switch 2
(number of
positions)
2P 3P 2P 3P
Flight
Mode
1
Launch Launch Launch Launch Launch Launch
2 Cruise Cruise Cruise Cruise Cruise Cruise
3 Land Land Land
4 Thermal Thermal Thermal Thermal
5 Speed Speed
*Must be set up in a 4/5 flight mode
.

Spektrum DX9 Specifications

General

Interface	RF Wireless
Product color	Black
Brand compatibility	Spektrum
Compatible products	Spektrum BLADE 450X BNF[BLH4380A]\\r 300 CFX BNF Basic[BLH4650]\\r 300 CFX BNF Basic[BLH4650]\\r Nano QX FPV RTF w/ SAFE[BLH7200]
Backlight color	Blue
Built-in display	Yes
Maximum range	- m
Frequency band	2.4 GHz
Language version	English
Channels quantity	9 channels
Number of devices supported	1
Battery capacity	2000 mAh

Weight and Dimensions

Weight	- g
