SPEKTRUM DX9 • TRANSMITTER INSTRUCTION MANUAL
EN
Aileron to Rudder
TheAilerontoRuddermixiscommonlyusedforcoordinated
turns. When active, as aileron is applied the rudder moves in
the same direction as the turn (right aileron input results in right
rudder output). If you assign the flight mode to a switch, a Sub
Switch option allows you to assign an additional switch to activate
upto3AilerontoRuddermixesforthatightmode.
Aileron to Flap
TheAilerontoFlapmixallowstheentiretrailingedgeofthewing
(aileron and flap) to operate as ailerons. When active, as aileron is
applied the flaps also move. Always program the flaps to move in
the same direction as the turn (so that right aileron is equivalent to
flaps moving as right ailerons).
Elevator to Flap
ElevatortoFlapmixcreatesadditionallift,allowingatighterturn.
The entire trailing edge of the wing (aileron and flap) operates
as flaps (camber increase) when you apply elevator. An offset is
provided, which is typically used for Snap Flaps. With Snap Flap,
noElevatortoFlapmixoccursuntiltheoffsetvalueisreached.
Typically, this offset is at 70% up elevator so that beyond 70%
thedownapmixcomesin,providingadditionalliftformore
aggressive turning (for tight thermals or racing turns).
Flap to Elevator
FlaptoElevatormixpreventspitchuptendencythatoccurswhen
youapplyCroworButtery.Thismixistypicallyusedonlywiththe
CamberSystem.TheFlaptoElevatormixoperatesasacurveso
that the elevator moves down the most during the first 20% of flap
deployment,decreasesoverthenext40%,thenremainsthesame
from 60 to 100% of flap travel.
For sailplanes with ailerons/tips/flaps, make sure an appropriate
Sailplane Type is selected so that tips appear in the transmitter as
RAIL and LAIL. Decrease or increase travel on the tip ailerons by
creatinganAIL>RAILmix.
SAIL Mixing
Foreachofthesemixes,youcanprogrameachightmodewithdifferentmixvaluesorat0%ifnomixisdesiredforthatspecicight
mode. Programming values include independent control of the direction and amount a slave surface moves in relationship to the master
surface.
