Spektrum iX14+ - Page 32

Function
1 Antenna
2 LED
3 Right Trim
4 Right Knob
5 Switch E
6 Switch H
7 Switch G
8 Switch F
9
Throttle Tension and Ratchet
Adjustment (Mode 1,3)
10 Throttle Limit Switch (Mode 1,3)
11 Mode Change Screw
Function
12
Throttle/Aileron (Mode 1)
Elevator/Aileron (Mode 2)
Throttle/Rudder (Mode 3)
Elevator/Rudder (Mode 4)
13
Left/Right Gimbal Stick Tension
Adjustment*
14
Up/Down Gimbal Stick Tension
Adjustment*
15 Throttle Limit Switch (Mode 1,3)
16
Aileron Trim (Mode 1,2)
Rudder Trim (Mode 3,4)
17
Elevator Trim (Mode 2, 4)
Throttle Trim (Mode 1, 3)
