Spektrum iX14+ - Page 33

Function
18 Speaker
19 LCD Touchscreen
20
Elevator Trim (Mode 1,3)
Throttle Trim (Mode 2,4)
21
Rudder Trim (Mode 1,2)
Aileron Trim (Mode 3,4)
22
Throttle Tension and Ratchet
Adjustment (Mode 2,4)
23 Throttle Limit Switch (Mode 2,4)
24 Mode Change Screw
Function
25
Elevator/Rudder (Mode 1)
Throttle/Rudder (Mode 2)
Elevator/Aileron (Mode 3)
Throttle/Aileron (Mode 4)
26
Left/Right Gimbal Stick Tension
Adjustment*
27
Up/down Gimbal Stick Tension
Adjustment*
28 Throttle Limit Switch (Mode 2,4)
29 Switch C
30 Switch B
31 Switch A
32 Switch D
