Function
33 Switch I
34 Left Trim
35 Power Button
36 Left Rear Lever
37 Right Rear Lever
Function
38 Serial Interface Port
39 Audio Jack
40 Battery Cover
41 Micro Memory Card Port
42 USB-C Charge Port
* NOTICE: Always perform a stick tension test while turning the screws to ensure
stick tension is not too loose or too tight. Overtightening a screw can damage
the spring. Loosening a screw too far can cause a spring to fall out in the
transmitter and possibly damage the circuitry within.
