SPX FLOW Johnson pump - KGEF Parts List (Bracket 1 & 2)

52 Parts KGE/EN (1711) 6.5
10.10 Parts list and sectional drawing KGEF, Bearing bracket 1 and 2, KGEF18-4
/ KGEF20b-5
For general parts, see part list of basic construction
Figure 26:
Item Spare part Remark Qty Description Material
0100 1 lantern piece cast iron
0350 * 1 shaft sleeve bronze
0390 1 motor --
0400 1 bracket support steel
0450 * 1 gasket for 0350 --
0740 4 tap bolt steel
0870 2 hex. bolt steel
0880 2 spring washer spring steel
2340 1 spring washer stainless steel
0770077004400440 07000700
07010701
07300730
04300430 01300130 08600860 03800380 04100410 01500150
07200720
01100110
23502350
21202120
07600760
07500750
01600160
07800780
01700170
01400140
04200420
23402340
012001202300230021202120 01000100 07800780 03900390
03500350 04500450 08300830 08400840 2370237009000900
09100910 08800880
08700870
